500S (5902171) - Ferris 500S Series 48" Zero-Turn Mower, 25hp Briggs & Stratton 122 cm Mower Deck Group - Housing, Arbors, and Blades Group Parts Diagram

500S Series 48" Zero-Turn Mower, 25hp Briggs & Stratton

122 cm Mower Deck Group - Housing, Arbors, and Blades Group Parts Diagram

  • Title

0005

Ferris 84012339

DECK SHELL w/Decals

$

$

Currently unavailable

0010

Ferris 5025394SM

NUT, 3/8-16 HEX NYLOCK

$4.49

$

In Stock, Qty 20+

0

0020

Ferris 5416763FS

SPINDLE ASSEMBLY

$141.99

$

In Stock, only 2 left!

0

0030

Ferris 5105631S

BLADE SET, MULCH, 48 DECK

Note: (Set of 3 Blades)

$78.99

$

In Stock, only 1 left!

0

0040

Ferris 1656916SM

WASHER, SPRING 0.475I

$7.99

$

In Stock, Qty 20+

0

0050

Ferris 703579

HHCS, 7/16-14X1.25

Note: Torque blade mounint bolts to 55 ft-lbs (74,5 Nm))

$4.99

$

In Stock, Qty 20+

0

0060

Ferris 1759940YP

SPACER

$17.99

$

In Stock, only 2 left!

0

0070

Ferris 84006898

PULLEY

$16.99

$

Usually ships in 2-12 days

0

0080

Ferris 1927531SM

CAPSCREW-HEX HD 7/16-

Note: (Torque pulley mounting bolts to 50-60 ft-lbs (68-82 Nm)

$5.99

$

In Stock, Qty 10

0

0090

Ferris 5416972BFS

BAFFLE, FRONT

$97.99

$

Usually ships in 2-12 days

0

0100

Ferris 84008500

BAFFLE, Rear

$

$

Currently unavailable

0110

Ferris 84008501

BAFFLE, Rear

$

$

Currently unavailable

0120

Ferris 84008499

PLATE, Blockoff

$

$

Currently unavailable

0130

Ferris 704146

SCREW, HEX, 5/16-18X1

Note: (Torque spindle mounting bolts to 25-30 ft-lbs (34-41 Nm))

$3.99

$

In Stock, only 1 left!

0

0140

Ferris 703115

NUT

$3.49

$

In Stock, Qty 19

0

0150

Ferris 703185

BOLT, Round Head, Short Square Neck

$3.49

$

In Stock, Qty 20+

0

0160

Ferris 84008496

SUPPORT, DISCHARGE CHUTE, 48, CE - BLK

$

$

Currently unavailable

0170

Ferris 84011104

CHUTE, Discharge

$

$

Currently unavailable

0180

Ferris 5042555SM

ROD, BRAKE LINKAGE

$11.99

$

In Stock, only 3 left!

0

0190

Ferris 703350

WASHER

$4.49

$

In Stock, Qty 10

0

0200

Ferris 5025045SM

NUT, 5/16-24 HEX NYLO

$3.49

$

In Stock, Qty 17

0

0220

Ferris 1760936AYP

WELDMENT

$

$

Currently unavailable

0230

Ferris 5025146X12YP

BOLT, 3/8-16 X 1-1/2

$4.49

$

Usually ships in 2-12 days

0
