5021 E (531309639) - Husqvarna 21" Snow Blower (2007-07) Auger and Control Assembly Parts Diagram

21" Snow Blower

Auger and Control Assembly Parts Diagram

  • Title

1

Husqvarna 601505147

COVER, TOP

$

$

Not available

2

Husqvarna 601400002

SCREW, 10-24X.50 WAHH

$

$

Not available

3

Husqvarna 601505148

NUT, 1/4-10 SPEED J-TYPE

$

$

Not available

4

Husqvarna 601505149

SCREW 1/4-14 X .75

$

$

Not available

5

Husqvarna 601002153

BEARING, FLANGED

$

$

Not available

6

Husqvarna 601505152

SCREW 1/4-20 X 1.00

$

$

Not available

7

Husqvarna 601400080

WASHER, FLAT .281X.63

$

$

Not available

8

Husqvarna 601505153

NUT #10-24 HEX CONTROL LOCK

$

$

Not available

9

Husqvarna 601505154

NUT 1/4-20 HEX CONTROL LOCK

$

$

Not available

10

Husqvarna 601505133

SCREW 1/4-20X.75

$

$

Not available

11

Husqvarna 601505156

AUGER HOUSING ASSEMBLY

$359.99

$

Usually ships in 3-10 days

0

12

Husqvarna 601400073

SCREW .25-20X0.62 HHC

$

$

Not available

13

Husqvarna 601505157

AUGER ASSEMBLY, COMPLETE
(Superseded to 601001798)

$

$

Not available

14

Husqvarna 601505158

BLADE, SCRAPER

$125.99

$

Usually ships in 3-10 days

0

15

Husqvarna 601400074

PLATE & BEARING ASY

$

$

Not available

16

Husqvarna 601001381

RETAINER, BRNG

$

$

Not available

17

Husqvarna 601400086

NUT .25-20 HEX CTRLOCK

$7.99

$

Usually ships in 3-10 days

0

18

Husqvarna 601002087

SPACER, SLEEVE

$

$

Not available

19

Husqvarna 601002095

PULLEY, RIBBED 6" OD

$

$

Not available

20

Husqvarna 601505159

COVER, BELT

$

$

Not available

21

Husqvarna 601505160

COVER, BOTTOM

$

$

Not available

22

Husqvarna 601400076

KEY SET - 691959

$41.99

$

Usually ships in 3-10 days

0

23

Husqvarna 601000111

NUT, 5/8-32 IGN SWIT PLA

$

$

Not available

24

Husqvarna 601400044

WASHER .640X1.1X.05

$

$

Not available

25

Husqvarna 601505189

BULB, PRIMER

$

$

Not available

26

Husqvarna 601000102

NUT, 1/4-20 REGHEXKEPS

$

$

Not available

27

Husqvarna 601001358

SWITCH

$

$

Not available

28

Husqvarna 601505165

HOSE, PRIMER 9.5"

$

$

Not available

29

Husqvarna 601505166

PANEL, CONTROL

$

$

Not available

30

Husqvarna 601400070

GROMMET AND WASHER, ROP

$

$

Not available

31

Husqvarna 601505140

STARTER ROPE GRIP

$

$

Not available

32

Husqvarna 601505168

PANNEL ACCESS

$

$

Not available

33

Husqvarna 601505169

SCREW 1/4-20 X 1.25

$

$

Not available

34

Husqvarna 601001378

RIVET

$

$

Not available
