51620 - Toro 31cc Curved Shaft Trimmer (SN: 059000001 - 059999999) (1995) HANDLE ASSEMBLY MODEL NO. 51653 Parts Diagram

31cc Curved Shaft Trimmer

HANDLE ASSEMBLY MODEL NO. 51653 Parts Diagram

  • Title

1

Toro 3296-12

NUT-LOCK, NI

$1.49

$

In Stock, only 3 left!

0

2

Toro 92-6516

HOUSING RH

$

$

Not available

3

Toro 53-7290

TROUGH 1"

$

$

Not available

4

Toro 53-7120

GRIP - RUBBER

$

$

Not available

5

Toro 92-3275

LEAD WIRE ASM

$

$

Not available

6

Toro 92-3278

THROTTLE CABLE

$

$

Not available

7

Toro 53-7270

THROTTLE LEVER

$

$

Not available

8

Toro 218-557

SWITCH COVER

$

$

Not available

9

Toro 42-6000

SWITCH

$17.99

$

In Stock, Qty 10

0

10

Toro 92-6515

HOUSING LH

$

$

Not available

11

Toro 32105-12

SCREW

$2.99

$

In Stock, only 2 left!

0

13

Toro 610327

Clip-Shoulder Strap

$

$

Not available

14

Toro 92-3280

DRIVE SHAFT HSG ASM

$232.99

$

Usually ships in 3-6 days

0

15

Toro 683295

Assy.-Bracket, Handle (Incl. 4 Screws & 4 Nuts)

$

$

Not available

16

Toro 180286

Assy.-J-Handle (Incl. Ref. No.17 & 18)

$

$

Not available

17

Toro 612021

TUBE CLOSURE

$

$

Not available

18

Toro 612831

HANDLE NITRILE GRIP

$

$

Not available

19

Toro 614204

SCREW
(Superseded to 147539)

$

$

Not available

20

Toro 684502

MTG HDW&PLUG SET

$

$

Not available

21

Toro 684501

Assembly-Gear Box (Incl. Ref. No. 27 & 28)
(Superseded to 147488)

$

$

Not available

22

Toro 147492

GUARD MOUNT

$

$

Not available

23

Toro 92-3236

FLEXIBLE DRIVE SHAFT

$

$

Not available

24

Toro 683304

GUARD MNTG SCREW ASM

$

$

Not available

25

Toro 92-3237

Assy.-Guard & Blade (Incl. Ref. #26)

$

$

Not available

26

Toro 682061

Assembly-Blade (Incl. 2 Screws & 2 Nuts)

$24.99

$

In Stock, only 1 left!

0

27

Toro 614200

Driver-Blade
(Superseded to 147489)

$37.92

$

In Stock, only 1 left!

0

28

Toro 614201

Blade Retaining Washer
(Superseded to 147490)

$15.99

$

Usually ships in 3-6 days

0

29

Toro 613231

BLADE SAFETY GUARD

$

$

Not available

30

Toro 612031

Blade (Incl. Ref. No.29)

$

$

Not available

31

Toro 613221

BLADE RETAINER NUT

$

$

Not available

32

Toro 612483

SPOOL SHAFT

$40.16

$

In Stock, only 1 left!

0

33

Toro 147494

Outer Spool & Eyelet Asm.
(Superseded to 683301)

$

$

Not available

34

Toro 145566

EYELET

$

$

Not available

35

Toro 612026

RETAINER ( 10 PACK)

$

$

Not available

36

Toro 610636

SPRING

$

$

Not available

37

Toro 147495

INNER REEL

$

$

Not available

38

Toro 147496

Assy.-Bump Head
(Superseded to 180814)

$

$

Not available

39

Toro 612486

Bolt-Bump Head
(Superseded to 180814)

$

$

Not available

Toro 92-3288

Spool & 40 ft. Line (Dual).
(Superseded to 92-3251)

Note: Not illustrated

$58.99

$

Usually ships in 3-6 days

0

Toro 41-6820

#1 BULK SPOOL .095

Note: Not illustrated

$45.99

$

Usually ships in 3-6 days

0

Toro 682075

STRAP SHOULDER ACC

Note: Not illustrated

$

$

Not available

Toro 66-2090

Toro 2-Cycle Oil

Note: Not illustrated

$

$

Not available

Toro 613226

LOCKING ROD TOOL

Note: Not illustrated

$

$

Not available

Toro 147498

Assembly-Cutting Head (Incl. Ref. No.32-39)

Note: Not illustrated

$

$

Not available
