51998 - Toro 18" Straight-Shaft String Trimmer (SN: 315000001 - 315999999) (2015) Powerhead Assembly No. 308466018 Parts Diagram

18" Straight-Shaft String Trimmer

Powerhead Assembly No. 308466018 Parts Diagram

  • Title

1

Toro 660344001

SCREW-PH

$2.99

$

Usually ships in 3-6 days

0

2

Toro 300754031

HOUSING-ENGINE, FRONT

$57.99

$

Usually ships in 3-6 days

0

3

Toro 660353001

SCREW-CLUTCH

$2.99

$

In Stock, only 2 left!

0

4

Toro 690696001

WASHER-CURVED

$2.99

$

In Stock, only 2 left!

0

5

Toro 300756007

See Supercession: 307091001
(Superseded to 307091001)

$

$

Not available

6

Toro 690695001

DISCONTINUED

$

$

Not available

7

Toro 690689001

NUT-ROTOR

$2.99

$

Usually ships in 3-6 days

0

8

Toro 640574002

ROTOR

$45.99

$

Usually ships in 3-6 days

0

9

Toro 300749010

CRANKCASE ASM

$173.99

$

Usually ships in 3-6 days

0

10

Toro 690688001

KEY-WOODRUFF

$2.99

$

Usually ships in 3-6 days

0

11

Toro 290178024

COIL BOOT ASM

$53.99

$

In Stock, only 2 left!

0

12

Toro 660349001

SCREW-PH

$2.99

$

Usually ships in 3-6 days

0

13

Toro 290143002

WIRE-LEAD, RED

$2.99

$

Usually ships in 3-6 days

0

14

Toro 290143001

WIRE-LEAD, BLACK

$2.99

$

Usually ships in 3-6 days

0

15

Toro 660347001

SCREW-PH

$2.99

$

In Stock, only 3 left!

0

16

Toro 638027002

SHIELD-HEAT

$13.99

$

Usually ships in 3-6 days

0

17

Toro 300748021

MUFFLER ASM

$88.99

$

Usually ships in 3-6 days

0

18

Toro 630002032

GASKET-MUFFLER

$4.99

$

Usually ships in 3-6 days

0

19

Toro 870170001

SPARK PLUG

$26.99

$

Usually ships in 3-6 days

0

20

Toro 630002021

PLATE-CYLINDER

$4.49

$

Usually ships in 3-6 days

0

21

Toro 660342001

SCREW-SOCKET HEAD

$2.99

$

Usually ships in 3-6 days

0

22

Toro 660351002

SCREW-PH, TORX

$2.99

$

Usually ships in 3-6 days

0

23

Toro 640570023

CYLINDER

$

$

Not available

24

Toro 900709005

GASKET

$

$

Not available

25

Toro 660563001

See Supercession: 660734001
(Superseded to 660734001)

$2.99

$

Usually ships in 3-6 days

0

26

Toro 591644001

HOUSING-ENGINE, REAR

$5.99

$

Usually ships in 3-6 days

0

27

Toro 660351001

SCREW-PH

$2.99

$

In Stock, Qty 10

0

28

Toro 308430016

RECOIL STARTER AND STARTER CUP ASM

$

$

Not available

29

Toro 900711008

See Supercession: 900711014
(Superseded to 903279002)

$

$

Not available

30

Toro 518329001

INSULATOR-DAM, HEAT

$17.99

$

Usually ships in 3-6 days

0

31

Toro 901697001

GASKET

$2.99

$

In Stock, only 3 left!

0

32

Toro 660344003

SCREW-PH

$2.99

$

Usually ships in 3-6 days

0

33

Toro 308480001

CARBURETOR ASM

$

$

Not available

34

Toro 308478004

FILTER HOUSING ASM

$23.99

$

In Stock, Qty 8

0

35

Toro 590458001

LEVER-CHOKE

$2.99

$

In Stock, only 2 left!

0

36

Toro 518130001

PLATE-CARBURETOR

$8.99

$

In Stock, only 1 left!

0

37

Toro 590946001

PLATE-CHOKE

$2.99

$

Usually ships in 3-6 days

0

38

Toro 660345001

SCREW-PH

$2.99

$

Usually ships in 3-6 days

0

39

Toro 300780002

PRIMER ASM

$

$

Not available

40

Toro 660346001

SCREW-PH

$2.99

$

In Stock, only 3 left!

0

41

Toro 560873001

ELEMENT-FILTER, AIR

$

$

Not available

42

Toro 308890002

COVER ASM

$8.49

$

In Stock, Qty 8

0

43

Toro 900711003

See Supercession: 9071103
(Superseded to 9071103)

$

$

Not available

44

Toro 690699001

CLIP-HOSE
(Superseded to 6969901)

$3.49

$

In Stock, Qty 16

0

45

Toro 570373002

LINE-FUEL

$2.99

$

In Stock, only 3 left!

0

46

Toro 690700001

CLIP-HOSE

$2.99

$

Usually ships in 3-6 days

0

47

Toro 308675063

FUEL TANK AND CAP ASM

$

$

Not available

48

Toro 940654088

LABEL-COMBUSTION

$2.99

$

Usually ships in 3-6 days

0

49

Toro 310816005

CAP-FUEL

$9.99

$

Usually ships in 3-6 days

0

50

Toro 310976001

FILTER-FUEL

$

$

Not available

51

Toro 660354001

SCREW

$3.49

$

Usually ships in 3-6 days

0

52

Toro 590462001

SPACER

$

$

Currently unavailable

53

Toro 690969001

WASHER

$

$

Currently unavailable

54

Toro 940865001

PLATE-LOGO

$2.99

$

Usually ships in 3-6 days

0

55

Toro 940686148

DECAL-START

$2.99

$

Usually ships in 3-6 days

0

56

Toro 638268001

SCREEN

$2.99

$

In Stock, only 3 left!

0

57

Toro 660870001

SCREW-PH

$2.99

$

Usually ships in 3-6 days

0
