528 SWE (31AH5LTT756) - Cub Cadet 28" Snow Thrower (2006) Cylinder Assembly Parts Diagram

28" Snow Thrower

Cylinder Assembly Parts Diagram

  • Title

1

Cub Cadet TC-35371

Cylinder (Cast Iron Liner) (3-5/16")

Note: Incl. 2, 20 & 72)

$311.99

$

Usually ships in 3-12 days

0

2

Cub Cadet TC-27652

Dowel Pin

$2.49

$

In Stock, only 1 left!

0

3

Cub Cadet TC-650820

Screw, 1/4-20 x 1/2"

$3.99

$

In Stock, Qty 20+

0

90

Cub Cadet TC-611094

Flywheel (w/ring gear)

$

$

Not available

100

Cub Cadet TC-35135A

Solid State Ignition (Incl. 101)
(Superseded to TC-35135B)

$62.99

$

In Stock, only 4 left!

0

101

Cub Cadet TC-610118

Spark Plug Cover

$6.49

$

In Stock, Qty 19

0

102

Cub Cadet TC-651024

Solid State Mounting Stud

$3.99

$

In Stock, Qty 7

0

103

Cub Cadet TC-651007

Screw, T-15, 10-24 x 15/16"

$1.99

$

In Stock, Qty 5

0

130

Cub Cadet TC-6021A

Screw, 5/16-18 x 1-1/2"

$1.99

$

In Stock, Qty 7

0

130A

Cub Cadet TC-650727

Screw, 5/16-18 x 1-3/4"

$3.99

$

Usually ships in 3-12 days

0

130C

Cub Cadet TC-651055

Screw, 5/16-18 x 39/64"

$

$

Not available

169

Cub Cadet TC-27896A

Valve Cover Gasket

$1.49

$

In Stock, Qty 20+

0

170

Cub Cadet TC-28423

Breather Body

$13.99

$

In Stock, only 2 left!

0

171

Cub Cadet TC-28424

Breather Element

$3.99

$

In Stock, Qty 20+

0

172

Cub Cadet TC-28425

Valve Cover

$7.49

$

In Stock, only 4 left!

0

173

Cub Cadet TC-35350

Breather Tube

$6.49

$

In Stock, Qty 12

0

174

Cub Cadet TC-650128

Screw, 10-24 x 1/2"

$5.49

$

In Stock, only 2 left!

0

178

Cub Cadet TC-29752

Nut & Lock Washer 1/4-28

$1.99

$

In Stock, Qty 5

0

182

Cub Cadet TC-30088A

Screw, 1/4-28 x 1"

$1.99

$

In Stock, only 1 left!

0

207

Cub Cadet TC-33878

Throttle Link

$6.99

$

In Stock, only 2 left!

0

222

Cub Cadet TC-28820

Screw, 10-32 x 1/2"
(Superseded to TC-651081)

$4.49

$

In Stock, Qty 6

0

260

Cub Cadet TC-37961

Blower Housing

Note: Painted Black with cooling holes

$

$

Not available

264A

Cub Cadet TC-650802

Screw, 1/4-20 x 5/8"

$1.99

$

In Stock, only 2 left!

0

275

Cub Cadet TC-35056

Muffler

$62.99

$

In Stock, Qty 5

0

276

Cub Cadet TC-31588

Locking Plate

$4.99

$

In Stock, Qty 20+

0

277

Cub Cadet TC-651002

Screw, 5/16-18 x 4-3/16"

$4.49

$

In Stock, Qty 20+

0

298

Cub Cadet TC-650665

Screw, 1/4-15 x 3/4"

$1.99

$

In Stock, Qty 6

0

311

Cub Cadet TC-27625

Oil Fill Plug Incl. 312)

$2.49

$

In Stock, Qty 14

0

314

Cub Cadet TC-650873

Screw, 1/4-20 x 3/4"

$1.99

$

Usually ships in 3-12 days

0

315

Cub Cadet TC-611104

Alternator Coil (3/5 Split)

Note: Incl. 321-323

$146.99

$

Usually ships in 3-12 days

0

321

Cub Cadet TC-611161

Diode

$17.99

$

In Stock, only 2 left!

0

322

Cub Cadet TC-611142

Connector Body

$3.99

$

Usually ships in 3-12 days

0

323

Cub Cadet TC-611118

Terminal

$1.99

$

Usually ships in 3-12 days

0

361

Cub Cadet TC-650990

Screw, Torx T-30, 1/4-20 x 15/32"

$3.99

$

In Stock, Qty 16

0

361A

Cub Cadet TC-650819

Screw, 6-32 x 2-1/2"

$1.99

$

In Stock, only 3 left!

0

380

Cub Cadet TC-640349

Carburetor (Incl.184)

$109.99

$

In Stock, only 1 left!

0

396

Cub Cadet TC-33329D

Electric Starter Motor (120 Volt)
(Superseded to TC-33329H)

$

$

Not available

396

Cub Cadet TC-33329E

Electric Starter Motor 120 Volt
(Superseded to TC-33329H)

$

$

Not available

999

Cub Cadet n/a

Winter Maintenance Kit

$

$

Currently unavailable

999

Cub Cadet n/a

Winter Maintenance Kit

$

$

Currently unavailable
