57300 (8-32) - Toro Lawn Tractor (SN: 007000001 - 007999999) (1977) STEERING WHEEL & DASH ASSEMBLY Parts Diagram

Lawn Tractor

STEERING WHEEL & DASH ASSEMBLY Parts Diagram

  • Title

1

Toro 28-3820

Steering Wheel

$

$

Not available

2

Toro 28-3800

Cap Steering Wheel (Model #57351)

$

$

Not available

Toro 28-3790

Cap Steering Wheel (Model #57300)

Note: Not illustrated

$

$

Not available

3

Toro 28-3960

Tube Steering

$

$

Not available

4

Toro 32144-12

Screw

$

$

Not available

5

Toro 233-25

KNOB-CONTROL

$5.49

$

In Stock, only 1 left!

0

6

Toro 28-0090

Throttle Control (Incl. Ref. #5)
(Superseded to 38-0990)

$124.99

$

Usually ships in 3-6 days

0

7

Toro 218-412

Key
(Superseded to 62-7770)

$4.99

$

In Stock, Qty 12

0

8

Toro 218-461

NUT-HH

$3.99

$

In Stock, Qty 18

0

9

Toro 3254-5

WASHER-TOOTH, INTERNAL

$1.49

$

In Stock, Qty 13

0

10

Toro 28-2690

DASH PANEL INSERT

$

$

Not available

11

Toro 218-497

NUT-BULB

$

$

Not available

12

Toro 218-498

NUT-LOCK

$0.99

$

In Stock, only 2 left!

0

13

Toro 28-2510

DASH PANEL INSERT

$

$

Not available

Toro 28-2500

DASH PANEL INSERT

Note: Not illustrated

$

$

Not available

14

Toro 28-4110

Light Switch (Incl. Ref. #11 & 12) (Model #57351)

$46.99

$

Usually ships in 3-6 days

0

15

Toro 32144-11

SCREW-HWHTF

$7.99

$

In Stock, Qty 8

0

16

Toro 28-9480

Decal-Deck Engagement

$

$

Currently unavailable

17

Toro 29-4780

EDGE MOULDING

$

$

Not available

18

Toro 237-100

GROMMET

$11.99

$

Usually ships in 3-6 days

0

19

Toro 27-9080

BEARING-FLANGE

$3.99

$

In Stock, Qty 6

0

20

Toro 28-9410

Shield Wire Harness
(Superseded to 36-1570)

$

$

Not available

21

Toro 18-2970

CLIP-FUEL LINE

$9.99

$

In Stock, only 4 left!

0

22

Toro 32144-10

SCREW-HWH

$4.99

$

In Stock, Qty 12

0

23

Toro 32144-1

SCREW-TAPTITE

$3.49

$

In Stock, Qty 20+

0

24

Toro 28-4450

DECK INTERLOCK SWITCH

$

$

Not available

25

Toro 32146-6

Nut
(Superseded to 3296-6)

$1.99

$

In Stock, Qty 20+

0

26

Toro 32151-48

E-RING

$1.99

$

In Stock, Qty 20+

0

27

Toro 28-2490

Steering Link
(Superseded to 36-3470)

$

$

Not available

28

Toro 27-8940

Follower Steering Shaft
(Superseded to 37-0140)

$

$

Not available

29

Toro 28-3930

Steering Shaft
(Superseded to 33-4530)

$

$

Not available

30

Toro 28-0320

Bracket-Steering
(Superseded to 36-2040)

$

$

Not available

31

Toro 23-0660

Ignition Switch (Incl. Ref. #8 & 9)

$22.99

$

Usually ships in 3-6 days

0

32

Toro 28-3940

STRG SHAFT COLLAR

$60.99

$

Usually ships in 3-6 days

0

33

Toro 32121-31

PIN-SPRING

$0.99

$

Usually ships in 3-6 days

0

34

Toro 27-8930

Bearing-Steering Shaft
(Superseded to 37-0150)

$

$

Not available

35

Toro 28-0390

STRG BRG SUPPORT

$

$

Not available

36

Toro 28-3950

Collar Steering Shaft

$

$

Not available

37

Toro 28-2460

DASH PANEL

$

$

Not available

38

Toro 32121-78

PIN-ROLL

$3.49

$

In Stock, Qty 7

0

39

Toro 28-4300

Wire Harness Light

$

$

Not available

40

Toro 28-9200

Wire Harness

$

$

Not available

41

Toro 28-7880

SOLENOID WIRE

$

$

Not available

42

Toro 28-3890

WIRE ASM

$

$

Not available

43

Toro 28-3860

WIRE ASM

$36.99

$

Usually ships in 3-6 days

0

44

Toro 32104-76

SCREW-HWHTF

$2.99

$

In Stock, Qty 20+

0
