580.328360 (8893-0) - Craftsman 7,500 Watt Portable Generator Mounting Base No. 69643 Parts Diagram

7,500 Watt Portable Generator

Mounting Base No. 69643 Parts Diagram

  • Title

1

Briggs & Stratton 68899

ENGINE - 18 HP Electric Start

$

$

Currently unavailable

2

Briggs & Stratton 69523

BASE ASSEMBLY, Mounting

$

$

Currently unavailable

3

Briggs & Stratton 69522

FRAME, Cradle

$

$

Currently unavailable

4

Briggs & Stratton 27028

NUT, Lock - 5/16"-18
(Superseded to 27028GS)

$3.49

$

Usually ships in 2-12 days

0

5

Briggs & Stratton 69524

SUPPORT, Fuel Tank

$

$

Currently unavailable

6

Briggs & Stratton 66431

TANK, Fuel - 4.5 gallon

$

$

Currently unavailable

7

Briggs & Stratton 64680C

COVER, Spark Plug Access

$

$

Currently unavailable

8

Briggs & Stratton 66802A

CAP, Fuel Tank Filler

$

$

Currently unavailable

9

Briggs & Stratton 66391B

GAUGE, Fuel Level

$

$

Not available

10

Briggs & Stratton 52749

SCREW - M5-0.80 x 12mm

$

$

Currently unavailable

11

Briggs & Stratton 36933

SCREW - No. 10-32 x 3/8"

$

$

Not available

12

Briggs & Stratton 22152

WASHER, Lock - No. 10
(Superseded to 5022152)

$32.99

$

Usually ships in 2-12 days

0

13A

Briggs & Stratton 48031C

CLAMP, Fuel Hose - 1/4"

$

$

Not available

13B

Briggs & Stratton 48031B

CLAMP, Fuel Hose - 3/16"
(Superseded to 48031BGS)

$3.49

$

Usually ships in 2-12 days

0

14A

Briggs & Stratton 68736

HOSE, Fuel - 3-1/2" long x 3/16" diameter

$

$

Currently unavailable

14B

Briggs & Stratton 47662AE

HOSE, Fuel - 12" long x 1/4" diameter

$

$

Currently unavailable

14C

Briggs & Stratton 47662AL

HOSE, Fuel - 3-1/2" long x 1/4" diameter

$

$

Currently unavailable

15

Briggs & Stratton 69254

SCREW (Crimptite) - 1/4"-20 x 1/2"

$

$

Currently unavailable

16

Briggs & Stratton 49451A

WASHER, Flat - 1.87" OD

$

$

Currently unavailable

17

Briggs & Stratton 22237

WASHER, Lock - 3/8"

$

$

Not available

18

Briggs & Stratton 66838B

STRAINER, Fuel Tank

$

$

Not available

19

Briggs & Stratton 38353

MOUNT, Vibration
(Superseded to 38353GS)

$39.99

$

Usually ships in 2-12 days

0

20

Briggs & Stratton 22145

WASHER, Flat - 5/16"

$

$

Not available

21

Briggs & Stratton 69530

PROBE, Oil Makeup

$

$

Currently unavailable

22

Briggs & Stratton 68893

ADAPTER, Fuel Hose - 1/4" to 3/16"

$

$

Currently unavailable

23

Briggs & Stratton 24489

SCREW (Taptite) - No. 10-32 x 3/8"

$

$

Currently unavailable

24

Briggs & Stratton 25433

LUG, Grounding

$

$

Not available

25

Briggs & Stratton 68896

TUBE, Lifting

$

$

Currently unavailable

26

Briggs & Stratton 22531

SCREW - 5/16"-18 x 1-3/4"
(Superseded to 5022531)

$19.99

$

Usually ships in 2-12 days

0

27

Briggs & Stratton 30449

CAP, Oil Makeup Tank

$

$

Not available

28

Briggs & Stratton 48084

TANK, Oil Makeup

$

$

Currently unavailable

29

Briggs & Stratton 67210A

DECAL, Grounding
(Superseded to 67210AGS)

$3.49

$

Usually ships in 2-12 days

0

30

Briggs & Stratton 68880

DECAL, Fuel Caution

$

$

Currently unavailable

31

Briggs & Stratton 68740

FILTER, Fuel
(Superseded to 68740GS)

$11.99

$

Usually ships in 2-12 days

0

32

Briggs & Stratton 69537

SWITCH ASSEMBLY, Low Oil Shutdown

$

$

Currently unavailable

33

Briggs & Stratton 47662N

HOSE - 3/8" ID x 7-1/4" long

$

$

Currently unavailable

34

Briggs & Stratton 35472

CLAMP, Hose - No. 6

$

$

Currently unavailable

35

Briggs & Stratton 46509

PUMP, Oil Makeup

$

$

Currently unavailable

36

Briggs & Stratton 35461

FITTING, Barbed

$

$

Not available

37

Briggs & Stratton 48031E

CLAMP, Hose - 3/8"

$

$

Currently unavailable

38

Briggs & Stratton 53030

CONTACTOR, Starter
(Superseded to 53030GS)

$57.99

$

Usually ships in 2-12 days

0

39

Briggs & Stratton 65121

BRACKET, Starter Contactor

$

$

Currently unavailable

40

Briggs & Stratton 22287

SCREW - 1/4"-20 x 3/4"
(Superseded to 22287GS)

$3.49

$

Usually ships in 2-12 days

0

41

Briggs & Stratton 22097

WASHER, Lock - 1/4"
(Superseded to 5022097)

$2.99

$

Usually ships in 2-12 days

0

42

Briggs & Stratton 22127

NUT, Hex - 1/4"-20

$

$

Not available

43

Briggs & Stratton 47662Q

HOSE - 3/8" ID x 18" long

$

$

Currently unavailable

44

Briggs & Stratton 69688

FITTING, Barbed

$

$

Currently unavailable

45

Briggs & Stratton 69521

SHIELD, Heat

$

$

Currently unavailable

46

Briggs & Stratton 26772

NUT, Lock - 1" NPT
(Superseded to 26772GS)

$5.49

$

Usually ships in 2-12 days

0

47

Briggs & Stratton 32202

NIPPLE, Pipe - 1" NPT x 3-1/2" long

$

$

Currently unavailable

48

Briggs & Stratton 32201

ELBOW, Reducing - 1" NPT to 1-1/4" NPT

$

$

Currently unavailable

49

Briggs & Stratton 69664

MUFFLER, Spark Arrest

$

$

Currently unavailable

50

Briggs & Stratton 69665

U-BOLT

$

$

Currently unavailable

51

Briggs & Stratton 69666

SUPPORT, Muffler

$

$

Currently unavailable

52

Briggs & Stratton 22241

NUT, Hex - 3/8"-16

$

$

Not available

53

Briggs & Stratton 69641

DECAL - SEARS CRAFTSMAN

$

$

Currently unavailable

54

Briggs & Stratton 23152

SCREW - 3/8"-16 x 3/4"
(Superseded to 5101614)

$450.99

$

Usually ships in 2-12 days

0
