588072 - Gravely Pro Series T Gear Drive Kit Wheel Clutch Arm Weldment Parts Diagram

Pro Series T Gear Drive Kit

Wheel Clutch Arm Weldment Parts Diagram

  • Title

1

Gravely 06542000

Nut-Locking-Flange .375-16
(Superseded to 06500822)

$1.49

$

In Stock, Qty 18

0

2

Gravely 58805200

Kit-Belt Cover with Decals

$67.99

$

Usually ships in 4-12 days

0

3

Gravely 06529400

Nut-Hex .38-16
(Superseded to 06500917)

$0.99

$

Usually ships in 4-12 days

0

4

Gravely 08875300

Bushing, Spacer, 3.25 x .38 I.D. x .63 O.D.

$5.99

$

Usually ships in 4-12 days

0

5

Gravely 05970400

Bolt-Hex .38-16 x 4.50 Grade 5
(Superseded to 05901938)

$4.99

$

Usually ships in 4-12 days

0

6

Gravely 06814900

Pin-Clevis .38 x 1.25

$3.99

$

In Stock, only 2 left!

0

7

Gravely 06713500

Pin-Hair Internal .08 x .18 x 1.18
(Superseded to 06700222)

$0.99

$

In Stock, Qty 14

0

8

Gravely 05957900

Bolt-Hex .38-16 x 1.50 Grade 5
(Superseded to 05901928)

$1.49

$

In Stock, Qty 5

0

9

Gravely 052617

Spring-Tension .105 x 1.00 x 5.00
(Superseded to 08346800)

$14.99

$

In Stock, only 2 left!

0

10

Gravely 06535800

Nut-Locking-Nylon .38-16
(Superseded to 06500831)

$2.49

$

In Stock, Qty 19

0

11

Gravely 06436200

Washer-Flat-Steel .406 x .812 x .065
(Superseded to 06401013)

$0.99

$

In Stock, Qty 20+

0

12

Gravely 049022

Bushing, Steel .385 x .610 x 1.80
(Superseded to 08831500)

$5.99

$

Usually ships in 4-12 days

0

13

Gravely 06537200

Nut-Locking-Jam-Center .38-16
(Superseded to 06500914)

$0.99

$

In Stock, Qty 20+

0

14

Gravely 06531000

Nut-Locking-Nylon .25-20
(Superseded to 06500832)

$4.99

$

In Stock, only 2 left!

0

15

Gravely 06537100

Nut-Nylock Wing .31-18

$5.99

$

In Stock, only 1 left!

0

16

Gravely 06435700

Washer-Flat-Steel .38 x .875 x .083
(Superseded to 06401023)

$1.49

$

In Stock, only 3 left!

0

17

Gravely 011779

Spring-Compression .125 x .78 x 1.00
(Superseded to 08327000)

$15.99

$

In Stock, only 4 left!

0

18

Gravely 045789

Bushing-Flange .32 x .62 x .312
(Superseded to 05517500)

$18.99

$

Usually ships in 4-12 days

0

19

Gravely 04928900

Bracket, Brake Link

$

$

Not available

20

Gravely 04935500

Rod, Brake

$30.99

$

Usually ships in 4-12 days

0

21

Gravely 049023

Weldment, Brake Arm
(Superseded to 08831600)

$74.99

$

Usually ships in 4-12 days

0

22

Gravely 06437200

Washer-Flat-Steel .344 x .688 x .065
(Superseded to 06401017)

$0.99

$

In Stock, Qty 11

0

23

Gravely 06706900

Pin-Cotter .09 x .75

$0.99

$

In Stock, Qty 5

0

24

Gravely 05946800

Bolt-Hex .25-20 x .75 Grade 5
(Superseded to 05901716)

$0.99

$

In Stock, Qty 12

0

25

Gravely 048870

Sheave 3.25 x 1.25
(Superseded to 07318400)

$22.99

$

In Stock, only 2 left!

0

26

Gravely 05963300

Bolt-Hex .38-16 x 2.00 Grade 5
(Superseded to 05901718)

$2.99

$

In Stock, Qty 11

0

27

Gravely 04923300

Bushing, Spacer

$3.49

$

Usually ships in 4-12 days

0

28

Gravely 04946200

Weldment- Wheel Clutch Arm

$93.99

$

Usually ships in 4-12 days

0

29

Gravely 04950500

Rod, Steering (988114, 115, 118, 119, 313, 315)

Note: (988114, 115, 118, 119, 313, 315)

$

$

Not available

29

Gravely 04947800

Rod, Steering Link (988100, 101, 102, 103, 104, 110, 112)

Note: (988100, 101, 102, 103, 104, 110, 112)

$24.99

$

Usually ships in 4-12 days

0
