5902195 - Ferris Venture X Series Stand-On Spreader Sprayer Spray Bar Group Parts Diagram

Venture X Series Stand-On Spreader Sprayer

Spray Bar Group Parts Diagram

  • Title

1

Ferris 84010285

STRAINER

$

$

Currently unavailable

2

Ferris 84010267

SPRING

$

$

Currently unavailable

3

Ferris 84010428

WASHER

$

$

Currently unavailable

4

Ferris 84009373

EYE BOLT

$

$

Currently unavailable

5

Ferris 5106576

SCR-CAP, HEX .3125"-18 X 1.000" SS188

$2.99

$

Usually ships in 2-12 days

0

6

Ferris 5107653

NUT-HEX-NYLK, FLG .3125"-18 SS188

$3.49

$

Usually ships in 2-12 days

0

7

Ferris 84013232

BUSHING, Snap (Bag of 2)

$

$

Currently unavailable

8

Ferris 84010341

TIP, SPRAY

$

$

Currently unavailable

9

Ferris 84013222

NOZZLE (Left)

Note: (Includes ref #1 and #8.)

$

$

Currently unavailable

10

Ferris 84013223

NOZZLE (Right)

Note: (Includes ref #1 and #8.)

$

$

Currently unavailable

11

Ferris 84013224

ARM, Sprayer (Left)

Note: (Includes ref #2, #3, #4, #5, and #6.)

$

$

Currently unavailable

12

Ferris 84013225

ARM, Sprayer (Right)

Note: (Includes ref #2, #3, #4, #5, and #6.)

$

$

Currently unavailable

13

Ferris 84013221

BAR, Spray (Center)

Note: (Includes ref #3, #4, #5, #6, and #7.)

$

$

Currently unavailable

100

Ferris 84013220

EYE BOLT ASSEMBLY

Note: (Includes ref #2, #4, and #6.)

$

$

Currently unavailable
