59B30036 (59B30036150) - Cub Cadet 72" Snow Blade Replacement Parts Parts Diagram

72" Snow Blade

Replacement Parts Parts Diagram

  • Title

1

Cub Cadet 603-0810A-0637

SKID SHOE

$84.99

$

Usually ships in 3-6 days

0

2

Cub Cadet 680-00026-0637

72" SNOW BLADE WELDMENT

$812.99

$

Usually ships in 3-6 days

0

3

Cub Cadet 680-00238-0637

SNOW BLADE FRAME

$1101.99

$

Usually ships in 3-6 days

0

3

Cub Cadet 936-0179

FLAT WASHER
(Superseded to 736-0179)

Note: (Not Shown)

$4.99

$

In Stock, Qty 20+

0

3

Cub Cadet 710-0773

SCREW 3/8-16 x .500

Note: (Not Shown)

$7.99

$

In Stock, Qty 20+

0

4

Cub Cadet 680-00243-0637

BLADE PIVOT BRACKET

$256.99

$

Usually ships in 3-6 days

0

5

Cub Cadet 680-00244-0637

LIFT ROD WELDMENT

$110.99

$

Usually ships in 3-6 days

0

6

Cub Cadet 680-00346A

BLADE MOUNTING SHAFT ASSEMBLY

Variations

680-00346A-0637

Cub Cadet 680-00346A-0637

BLADE MOUNTING SHA - POWDER BLACK (0637)

$106.99

$

Usually ships in 3-6 days

0

$92.99

$

Usually ships in 3-6 days

0

7

Cub Cadet 703-05971A-0637

72" SCRAPER BLADE

$183.99

$

Usually ships in 3-6 days

0

8

Cub Cadet 703-06856-0637

PLOW BRACKET

$23.99

$

Usually ships in 3-6 days

0

9

Cub Cadet 703-08774

WHEEL SPACER

Note: *CHOOSE COLOR WHEN ORDERING*

Variations

703-08774-0637

Cub Cadet 703-08774-0637

SPACER-WHEEL - POWDER BLACK (0637)

$68.99

$

Usually ships in 3-6 days

0

703-08774-4021

Cub Cadet 703-08774-4021

SPACER-WHEEL - CUB YELLOW 2 (4021)

$68.99

$

In Stock, only 2 left!

0

$55.99

$

Usually ships in 3-6 days

0

10

Cub Cadet 703-08833

PIVOT ROD PLATE

$39.99

$

Usually ships in 3-6 days

0

11

Cub Cadet 710-0451

CARRIAGE BOLT 5/16-18 x .75

$4.49

$

In Stock, Qty 20+

0

12

Cub Cadet 710-0489

SCREW 1/2-13 x 2 GR5

$7.99

$

Usually ships in 3-6 days

0

13

Cub Cadet 710-05456

SCREW 3/8-16 x 4.50

$3.99

$

Usually ships in 3-6 days

0

14

Cub Cadet 710-05458

SCREW 3/4-16 x 3.0

$12.99

$

Usually ships in 3-6 days

0

15

Cub Cadet 710-3005

SCREW 3/8-16 x 1.25 GR5

$4.49

$

In Stock, Qty 20+

0

16

Cub Cadet 710-3067

BOLT 1/2-13X1.75 GR5

$7.49

$

In Stock, only 2 left!

0

17

Cub Cadet 710-3096

SCREW 3/8-16 x 2.0 GR 8

$8.49

$

In Stock, Qty 20+

0

18

Cub Cadet 710-3168

CARRIAGE BOLT 3/8-16 x 1.00 GR5

$4.49

$

In Stock, Qty 20+

0

19

Cub Cadet 711-05731

CHAIN PIN

$

$

Not available

20

Cub Cadet 711-05735

CLEVIS PIN

$13.99

$

Usually ships in 3-6 days

0

21

Cub Cadet 711-05745

SNOW BLADE LIFT BAR

$36.99

$

Usually ships in 3-6 days

0

22

Cub Cadet 912-0206

HEX NUT
(Superseded to 712-0206)

$4.99

$

Usually ships in 3-6 days

0

23

Cub Cadet 712-04065

NUT

$4.49

$

In Stock, Qty 20+

0

24

Cub Cadet 712-04150

NUT

$4.99

$

In Stock, Qty 20+

0

25

Cub Cadet 712-04339

FLANGE NUT

$3.99

$

In Stock, only 1 left!

0

26

Cub Cadet 912-3017

HEX NUT
(Superseded to 712-3017)

$4.49

$

In Stock, Qty 11

0

27

Cub Cadet 712-3078

HEX FLANGE NUT 3/4

$10.99

$

In Stock, Qty 20+

0

28

Cub Cadet 714-0162

COTTER PIN-5/32 DIA

$5.49

$

In Stock, Qty 20+

0

29

Cub Cadet 714-04043

PIN:COTTER

$5.49

$

In Stock, Qty 20+

0

30

Cub Cadet 732-04959

ADJUSTMENT SPRING

$56.99

$

In Stock, only 2 left!

0

31

Cub Cadet 748-04075

SPACER:.385 ID x .63

$3.49

$

Usually ships in 3-6 days

0
