60 (0340002U) - International Harvester Riding Mower (1967 - 1971) Magneto - Recoil Start Engine Parts Diagram

Riding Mower

Magneto - Recoil Start Engine Parts Diagram

  • Title

Cub Cadet IH-488626-R91

MAGNETO

$

$

Currently unavailable

1

FLYWHEEL

Note: Not Available Seperately

$

$

Not available

2

SPRING, BREAKER BOX

Note: Not Available Seperately

$

$

Not available

3

COVER, BREAKER DUST

Note: Not Available Seperately

$

$

Not available

4

Cub Cadet IH-488627-R1

CAM, BREAKER

$

$

Not available

5

Cub Cadet IH-488631-R1

CONTACT ASSY, BREAKER
(Superseded to TC-30547A)

$18.99

$

In Stock, only 2 left!

0

6

Cub Cadet IH-131095

WASHER, NO 8 C-Z HV. LOCK

$

$

Currently unavailable

7

TAB, GROUND TERMINAL

Note: Not Available Seperately

$

$

Not available

8

Cub Cadet IH-120622

NUT, 8-32 C-Z HEX. MACH SCREW
(Superseded to 712-0142)

$4.99

$

In Stock, only 3 left!

0

9

SCREW AND WASHER, BREAKER

Note: Not Available Seperately

$

$

Not available

10

Cub Cadet IH-23163-R1

SCREW, 8-32 X 13/16 C-Z TYPE F SLT-HEX.

$

$

Currently unavailable

11

Cub Cadet IH-488637-R91

COIL ASSY
(Superseded to TC-30560A)

$48.99

$

In Stock, only 2 left!

0

12

WIRE, LEAD

Note: Not Available Seperately

$

$

Not available

13

Cub Cadet IH-488639-R1

CONDENSER
(Superseded to TC-30548B)

$13.99

$

In Stock, only 1 left!

0

14

CORE AND PLATE

Note: Not Available Seperately

$

$

Not available

15

Cub Cadet IH-488628-R1

STATOR ASSY

Note: CONSISTS OF REF NOS 2, 3, 5 THRU 14 AND 16 THRU 20

$

$

Currently unavailable

16

FELT, CAM WIPER

Note: Not Available Seperately

$

$

Not available

17

Cub Cadet IH-488643-R1

CLIP, COIL LOCKING

$

$

Not available

18

Cub Cadet IH-488640-R1

CLIP, COIL WEDGE SPRING

$

$

Currently unavailable

19

Cub Cadet IH-488644-R1

GASKET, DUST COVER

$

$

Currently unavailable

20

Cub Cadet IH-490947-R1

GASKET, DUST SHIELD

$

$

Currently unavailable
