61G377-0002-J1 - Briggs & Stratton Horizontal Engine Lubrication Group Parts Diagram

Horizontal Engine

Lubrication Group Parts Diagram

  • Title

273

SEAL, O-Ring

Note: (Part information located in Crankcase Cover/Sump Group.)

$

$

Not available

400

Briggs & Stratton 846249

COOLER, Oil

$83.99

$

Usually ships in 2-12 days

0

417

Briggs & Stratton 841233

SCREW

Note: (Oil Cooler) (M6x10mm)

$3.49

$

In Stock, only 3 left!

0

417A

Briggs & Stratton 846250

SCREW

Note: (Oil Cooler) (M6x16mm)

$4.99

$

Usually ships in 2-12 days

0

468

SEAL, O-Ring

Note: (Part information located in Crankcase Cover/Sump Group.)

$

$

Not available

479

SCREW

Note: (Part information located in Crankcase Cover/Sump Group.)

$

$

Not available

523

DIPSTICK

Note: (Part information located in Crankcase Cover/Sump Group.)

$

$

Not available

596

SCREW

Note: (Part information located in Crankcase Cover/Sump Group.)

$

$

Not available

601D

Briggs & Stratton 845209

CLAMP, Hose

$4.49

$

Usually ships in 2-12 days

0

750

SCREW

Note: (Part information located in Crankcase Cover/Sump Group.)

$

$

Not available

829A

Briggs & Stratton 846260

HOSE, Oil Cooler

$39.99

$

Usually ships in 2-12 days

0

829D

Briggs & Stratton 846259

HOSE, Oil Cooler

$46.99

$

Usually ships in 2-12 days

0

965

COVER, Oil Pump

Note: (Part information located in Crankcase Cover/Sump Group.)

$

$

Not available

1013

Briggs & Stratton 841602

NIPPLE, Oil Filter

$55.99

$

Usually ships in 2-12 days

0

1017

SCREEN, Oil Pump

Note: (Part information located in Crankcase Cover/Sump Group.)

$

$

Not available

1024

PUMP, Oil

Note: (Part information located in Crankcase Cover/Sump Group.)

$

$

Not available

1027

Briggs & Stratton 842921

FILTER, Oil

$14.99

$

In Stock, Qty 20+

0

1366

Briggs & Stratton 841510

DIVERTER, Oil Cooler

$87.99

$

Usually ships in 2-12 days

0

1374

Briggs & Stratton 796863

SEAL, O-Ring

Note: (Oil Cooler Diverter)

$5.99

$

In Stock, only 1 left!

0
