65-30MS01 - Toro 30" Side-Discharge Mower Deck (1976) A-70 RIDING MOWER PARTS LIST Parts Diagram

30" Side-Discharge Mower Deck

A-70 RIDING MOWER PARTS LIST Parts Diagram

  • Title

1

Toro 225106

Screw, Hex Hd, 6-20 x 7/16 In.

Note: Standard Hardware Items-May Be Purchased Locally.

$

$

Not available

2

Toro 225099

Clip, Headlamp Mounting

$

$

Not available

3

Toro 225477

Screw, Rd Hd, No. 8

Note: Standard Hardware Items-May Be Purchased Locally.

$

$

Not available

4

Toro 225210

Headlamp Holder, Front Console

$

$

Not available

5

Toro 225464

Decal, Dash

$

$

Not available

6

Toro 225460

Decal, Console Side, R.H.

$

$

Not available

7

Toro 225461

Decal, Console Side, L.H.

$

$

Not available

8

Toro 225223

Wellnut, No. 8-32

$

$

Not available

9

Toro 225474

Screw, Truss Hd, 1/4-20 Thd

Note: Standard Hardware Items-May Be Purchased Locally.

$

$

Currently unavailable

10

Toro 926496-4

Screw, Taptite, 5/16-18 x 3/4 In.

$

$

Currently unavailable

11

Toro 225414

Console

$

$

Not available

12

Toro 225181

Steering Shaft Shroud

$

$

Not available

13

Toro 933222

Roll Pin

$

$

Currently unavailable

14

Toro 225146

Steering Wheel

$

$

Not available

15

Toro 225420

Seat

$

$

Not available

16

Toro 908017-4

Bolt 5/16-18 x

Note: Standard Hardware Items-May Be Purchased Locally.

$

$

Currently unavailable

17

Toro 225113

Plate, Seat Mount

$

$

Not available

18

Toro 225147

Duct, Air Intake

$

$

Currently unavailable

19

Toro 225480

Screw, Truss Hd, 1/4-20 x 1 In.

Note: Standard Hardware Items-May Be Purchased Locally.

$

$

Currently unavailable

20

Toro 225417

Cover Assy, Rear Shroud, Incls. 40, 80, 83, 84, 85, 87, 88 & 89

$

$

Not available

21

Toro 225231

Pop Rivet, 1/8 In.

$

$

Not available

22

Toro 225148

Screen, Rear Cover

$

$

Not available

23

Toro 225149

Rim, Screen Retainer

$

$

Currently unavailable

24

Toro 225217

Grommet, Rubber

$

$

Not available

25

Toro 225233

Screw, Thumb, 1/4-20 Thd

$

$

Not available

26

Toro 225180

Exhaust Extension

$

$

Not available

27

Toro 9080024

Screw, Hex Hd, 1/4-20 x 5/8 In.

Note: Standard Hardware Items-May Be Purchased Locally.

$

$

Currently unavailable

28

Toro 225347

Rivet, 3/16 x 9/32 In .

$

$

Currently unavailable

29

Toro 225419

Cover Panel

$

$

Not available

30

Toro 225466

Decal, Cover Plate

$

$

Not available

31

Toro 225114

Plate, Seat Support

$

$

Not available

32

Toro 9200084

Washer
(Superseded to 3256-23)

Note: Standard Hardware Items-May Be Purchased Locally.

$2.49

$

In Stock, Qty 20+

0

33

Toro 915111-6

Nut-Nylok

$

$

Currently unavailable

34

Toro 920037-4

Washer

Note: Standard Hardware Items-May Be Purchased Locally.

$

$

Currently unavailable

35

Toro 225452

Decal, Parking Brake

$

$

Currently unavailable

36

Toro 225462

Decal, Blade Engage

$

$

Not available

37

Toro 908019-4

Bolt 5/16-18 x 1

Note: Standard Hardware Items-May Be Purchased Locally.

$

$

Currently unavailable

38

Toro 915968-4

Nut 1/4-20 Keps

Note: Standard Hardware Items-May Be Purchased Locally.

$

$

Currently unavailable

39

Toro 225227

Panel Clip

$

$

Currently unavailable

40

Toro 225191

Nut, Tinnerman, 1/4-20 Thd

Note: Standard Hardware Items-May Be Purchased Locally.

$

$

Not available

41

Toro 225512

Floor Pan

$

$

Currently unavailable

42

Toro 225432

Floot Mat

$

$

Not available

43

Toro 225463

Decal, Instruction

$

$

Not available

44

Toro 225235

Strap, Wiring

$

$

Not available

45

Toro 915112-6

Nut-Nylok

Note: Standard Hardware Items-May Be Purchased Locally.

$

$

Currently unavailable

46

Toro 225458

Decal, Cover Plate

$

$

Not available

47

Toro 915111-6

Nut-Nylok

Note: Standard Hardware Items-May Be Purchased Locally.

$

$

Currently unavailable

48

Toro 225308

Hinge

$

$

Not available

49

Toro 225418

Plate, Throttle Cover

$

$

Not available

50

Toro 225451

Decal, Throttle

$

$

Not available

51

Toro 225346

Backup Plate

$

$

Currently unavailable

52

Toro 225459

Decal, Shift Pattern

$

$

Not available

53

Toro 225232

Gas Gauge

$

$

Not available

54

Toro 225030

Washer

$

$

Currently unavailable

55

Toro 225309

Body Support

$

$

Not available

56

Toro 225319

Rivet, 3/16 x 3/8 In.

$

$

Currently unavailable

57

Toro 225415

Body

$

$

Not available

58

Toro 225216

Backing Plate

$

$

Not available

59

Toro 225218

Tee Nut

$

$

Not available

60

Toro 225247

Reflector

$

$

Not available

61

Toro 225318

Thumb Screw

$

$

Not available

62

Toro 225242

Plastic Cap

$

$

Not available

63

Toro 908021-4

Bolt 5/16-18 x 1/2

$

$

Currently unavailable

64

Toro 225011

Washer, Formed

$

$

Currently unavailable

65

Toro 225241

Bumper Tube

$

$

Not available

66

Toro 225110

Rubber Mount

$

$

Not available

67

Toro 915972-4

Nut 5/16-18 Keps

Note: Standard Hardware Items-May Be Purchased Locally.

$

$

Currently unavailable

68

Toro 225456

Decal, Body Side, R.H.

$

$

Not available

69

Toro 225457

Decal, Body Side, L.H.

$

$

Not available

70

Toro 225354

Pad, Body Guide

$

$

Currently unavailable

71

Toro 225143

Bracket, Throttle Mount

$

$

Currently unavailable

72

Toro 915962-4

Nut, Keps, No. 8

Note: Standard Hardware Items-May Be Purchased Locally.

$

$

Currently unavailable

73

Toro 225039

Knob

$

$

Not available

74

Toro 225313

Throttle Control

$

$

Not available

75

Toro 225122

Gas Tank

$

$

Not available

76

Toro 225150

Rubber Bushing

$

$

Not available

77

Toro 225196

Shut Off Cock
(Superseded to 104048)

$31.99

$

In Stock, Qty 5

0

78

Toro 225302

Strap, Gas Tank Support

$

$

Not available

79

Toro 225167

Plate, Gas Tank Support

$

$

Currently unavailable

80

Toro 225301

Strap, Muffler

$

$

Not available

81

Toro 225092

Hose Clamp

$

$

Not available

82

Toro 225197

Gas Line

$

$

Not available

83

Toro 225166

Battery Rack Assembly

$

$

Currently unavailable

84

Toro 225383

Main Frame

$

$

Currently unavailable

85

Toro 225311

Body, Rod Guide

$

$

Currently unavailable

86

Toro 225368

Bracket, Upstop

$

$

Currently unavailable

87

Toro 225118

Bracket, Rear Axle Support

$

$

Not available

88

Toro 225305

Chain Adjustment, Outer

$

$

Not available

89

Toro 908025-4

Bolt Hex 5/6-18 X 2-1/2

$

$

Currently unavailable

90

Toro 225304

Chain Adjustment, Inner

$

$

Currently unavailable

91

Toro 225240

Bumper Support, L.H.

$

$

Not available

92

Toro 225312

Trailer Hitch

$

$

Not available

93

Toro 908016-4

Bolt Hex 5/16-18

Note: Standard Hardware Items-May Be Purchased Locally.

$

$

Currently unavailable

94

Toro 225317

Tinnerman Nut

$

$

Not available

95

Toro 225239

Bumper Support, R.H.

$

$

Not available

96

Toro 225336

Service Rod (Not Illust.)

$

$

Currently unavailable
