7-1611 - Toro 44" Spiked Harrow (1969)

44" Spiked Harrow

7-1611 - Toro 44" Spiked Harrow (1969) > Parts Diagrams (1) > PARTS LIST-HARROW FACTORY ORDER NUMBER 7-1612 (FORMERLY 7-1611)

  • Title
2611

1

Frame Assembly

Part# 2611

OEM Warranty Repair Part for Toro

Currently unavailable

2641

2

Channel Assembly

Part# 2641

OEM Warranty Repair Part for Toro

Currently unavailable

2613

3

Handle Assembly

Part# 2613

OEM Warranty Repair Part for Toro

Currently unavailable

2626

4

Sector Assembly

Part# 2626

OEM Warranty Repair Part for Toro

Not available

2607

5

Hitch

Part# 2607

OEM Warranty Repair Part for Toro

Not available

2623

6

Adjusting Angle

Part# 2623

OEM Warranty Repair Part for Toro

Currently unavailable

2617

7

Locking Pin

Part# 2617

OEM Warranty Repair Part for Toro

Currently unavailable

2619

8

"U" Bolt

Part# 2619

OEM Warranty Repair Part for Toro

Currently unavailable

2621

9

Spike

Part# 2621

OEM Warranty Repair Part for Toro

Not available

2624

10

Spike Clamp

Part# 2624

OEM Warranty Repair Part for Toro

Not available

915184

11

Sq. Nut-3/8-16

Part# 915184

OEM Warranty Repair Part for Toro

Not available

909554

12

Screw-Set

Part# 909554 (Superseded to 3243-5)

OEM Warranty Repair Part for Toro

Usually leaves our warehouse in 1 business day

Your price: $1.27

2625

13

Spring

Part# 2625

OEM Warranty Repair Part for Toro

Not available

915112

14

Nut

Part# 915112 (Superseded to 3217-6)

OEM Warranty Repair Part for Toro

Usually leaves our warehouse in 1 business day

Your price: $1.00

915113

15

Nut

Part# 915113 (Superseded to 32153-2)

OEM Warranty Repair Part for Toro

Usually leaves our warehouse in 1 business day

Your price: $3.38

932017

16

See Supercession: 9320174

Part# 932017 (Superseded to 9320174)

OEM Warranty Repair Part for Toro

Usually leaves our warehouse in 5 to 8 business days

Your price: $0.35

920011

17

Washer

Part# 920011 (Superseded to 3256-26)

OEM Warranty Repair Part for Toro

Usually leaves our warehouse in 1 business day

Your price: $0.44

908036

18

BOLT

Part# 908036 (Superseded to 323-8)

OEM Warranty Repair Part for Toro

Usually leaves our warehouse in 1 business day

Your price: $2.37

908035

19

Bolt

Part# 908035 (Superseded to 323-7)

OEM Warranty Repair Part for Toro

Usually leaves our warehouse in 1 business day

Your price: $2.16

920009

20

Washer

Part# 920009 (Superseded to 3256-24)

OEM Warranty Repair Part for Toro

Usually leaves our warehouse in 1 business day

Your price: $0.49

1477

21

Eyebolt

Part# 1477

OEM Warranty Repair Part for Toro

Currently unavailable

920005

22

WASHER

Part# 920005

OEM Warranty Repair Part for Toro

Usually leaves our warehouse in 5 to 8 business days

Your price: $0.35

915563

23

Nut-Nylok #10-24

Part# 915563

OEM Warranty Repair Part for Toro

Currently unavailable

2610

24

Chain

Part# 2610

OEM Warranty Repair Part for Toro

Currently unavailable

103174

24

DECAL-WHEEL HORSE

Part# 103174

OEM Warranty Repair Part for Toro

Not available
