73520 (520-H) - Toro Garden Tractor (SN: 049000001 - 049999999) (1994) AIR CLEANER Parts Diagram

Garden Tractor

AIR CLEANER Parts Diagram

  • Title

1

Toro NN10187

AIR INTAKE TUBE

$

$

Not available

2

Toro 82-1550

SCREW-TAPPING

$

$

Not available

3

Toro 92-0915

MACHINE SCREW

$

$

Not available

4

Toro 92-0913

1/4-20 WING NUT

$

$

Not available

5

Toro 82-1670

KNOB

$

$

Not available

6

Toro NN10446

CHROME-AIR CLEANER

$

$

Not available

7

Toro 79-6520

SPACER-RUBBER

$

$

Not available

8

Toro 82-0650

ELEMENT COVER KIT

$

$

Not available

9

Toro NN10176

AIR CLEANER ELEMENT

$

$

Not available

10

Toro 79-6510

SPACER-1" LG

$

$

Not available

11

Toro 82-0660

ELEMENT-AIR CLEANER

$35.99

$

Usually ships in 3-6 days

0

12

Toro 79-6330

AIR-CLEANER HOUSING

$

$

Not available

13

Toro 79-6340

SUPPORT-AIR CLEANER

$

$

Not available

14

Toro NN10390

SCREW #10-32 X 5/8

$

$

Not available

15

Toro 59-1180

CONDENSER

$45.99

$

Usually ships in 3-6 days

0

16

Toro 3253-5

WASHER-LOCK

$0.99

$

In Stock, Qty 15

0

17

Toro 71-6140

GROMMET

$

$

Not available
