815008 - Gravely 42" Deck Grass Bagger for ZT Series (SN: 000101 & Above) Counterweight, Boots And Vanes Parts Diagram

42" Deck Grass Bagger for ZT Series

Counterweight, Boots And Vanes Parts Diagram

  • Title

1

Gravely 050373

Upper Boot
(Superseded to 03599600)

$

$

Not available

2

Gravely 01585800

Hose 7 x 45
(Superseded to 04222900)

$113.99

$

Usually ships in 4-12 days

0

3

Gravely 038532

Hose Clamp
(Superseded to 03022400)

$17.99

$

Usually ships in 4-12 days

0

4

Gravely 01585900

Mower Boot Assembly with Decal

$

$

Not available

5

Gravely 07532600

Knob

$17.99

$

Usually ships in 4-12 days

0

6

Gravely 05970500

Bolt-Hex .31-24 x .75 Grade 8
(Superseded to 05902019)

$2.49

$

Usually ships in 4-12 days

0

7

Gravely 51503500

Vane Service Assembly

$82.99

$

Usually ships in 4-12 days

0

8

Gravely 06537000

Nut-Locking Top .312-24

$1.49

$

In Stock, only 3 left!

0

9

Gravely 03640251

Counterweight

$387.99

$

Usually ships in 4-12 days

0

10

Gravely 06221000

Bolt-Round Head Square Neck .44 -14 x 4.50 Grade 2

$

$

Not available

11

Gravely 06536400

Nut .437-14
(Superseded to 06500930)

$2.99

$

Usually ships in 4-12 days

0

12

Gravely 51503600

Mower Boot Assembly - 42"

$

$

Not available

13

Gravely 01584500

22" Blade

$31.99

$

In Stock, Qty 20+

0
