827015 - Gravely 28", 32" Grass Bagger (SN: 000101 & Above) Boots, Vanes, And Tube Parts Diagram

28", 32" Grass Bagger

Boots, Vanes, And Tube Parts Diagram

  • Title

1

Gravely 52710000

28/32-In. Boot Assembly

$

$

Not available

2

Gravely 02746200

Tube Retainer

$19.99

$

Usually ships in 4-12 days

0

2

Gravely 050355

(Gravely Part Number)
(Superseded to 02746200)

Note: (Gravely Part Number)

$19.99

$

Usually ships in 4-12 days

0

3

Gravely 06803800

Rivet-Pop .187 x .527

$1.49

$

In Stock, Qty 20+

0

3

Gravely 041098

(Gravely Part Number)
(Superseded to 06803800)

Note: (Gravely Part Number)

$1.49

$

In Stock, Qty 20+

0

4

Gravely 02750800

Boot Support

$

$

Not available

4

Gravely 050364

(Gravely Part Number)
(Superseded to 02750800)

Note: (Gravely Part Number)

$

$

Not available

5

Gravely 06803900

Rivet-Pop .187 x .277

$

$

Not available

5

Gravely 050367

(Gravely Part Number)
(Superseded to 06803900)

Note: (Gravely Part Number)

$

$

Not available

6

Gravely 06802500

Rivet-Pop .187 x .402

$1.49

$

In Stock, Qty 11

0

7

Gravely 02746100

Boot Bracket

$17.99

$

Usually ships in 4-12 days

0

7

Gravely 050363

(Gravely Part Number)
(Superseded to 02746100)

Note: (Gravely Part Number)

$17.99

$

Usually ships in 4-12 days

0

8

Gravely 02746400

Lanyard

$21.99

$

Usually ships in 4-12 days

0

8

Gravely 050369

(Gravely Part Number)
(Superseded to 02746400)

Note: (Gravely Part Number)

$21.99

$

Usually ships in 4-12 days

0

9

Gravely 06807200

Rivet-Tubular .187 x .375 Steel-Aluminum

$

$

Not available

10

Gravely 02746300

Pull Pin

$29.99

$

In Stock, only 2 left!

0

10

Gravely 050368

(Gravely Part Number)
(Superseded to 02746300)

Note: (Gravely Part Number)

$29.99

$

In Stock, only 2 left!

0

11

12710028

Skirt, Rubber

$

$

Not available

12

Gravely 06442700

Washer-Flat-Steel .219 x .50 x .049
(Superseded to 06401123)

$0.99

$

Usually ships in 4-12 days

0

13

Gravely 06531000

Nut-Locking-Nylon .250-20
(Superseded to 06500832)

$4.99

$

In Stock, only 2 left!

0

14

Gravely 06437300

Washer-Flat-Steel .281 x .62 x .065
(Superseded to 06401001)

$0.99

$

In Stock, Qty 15

0

15

Gravely 05946800

Bolt-Hex .25-20 x .75 Grade 5
(Superseded to 05901716)

$0.99

$

In Stock, Qty 12

0

16

Gravely 02752000

28/32-In. Boot
(Superseded to 52707200)

$

$

Not available

17

Gravely 53602100

40-In. Boot Assembly

$230.99

$

Usually ships in 4-12 days

0

18

Gravely 03640400

40-In. Boot

$

$

Not available

19

Gravely 06442700

Washer-Flat-Steel .219 x .50 x .049
(Superseded to 06401123)

$0.99

$

Usually ships in 4-12 days

0

20

Gravely 02750600

Tube Retainer Clip

$17.99

$

Usually ships in 4-12 days

0

20

Gravely 050360

(Gravely Part Number)
(Superseded to 02750600)

Note: (Gravely Part Number)

$17.99

$

Usually ships in 4-12 days

0

21

Gravely 05970500

Bolt-Hex .31-24 x .75 Grade 8
(Superseded to 05902019)

$2.49

$

Usually ships in 4-12 days

0

22

Gravely 01609200

28- and 32-Inch Vane

$12.99

$

In Stock, only 1 left!

0

23

Gravely 06537000

Nut-Center-Lock .31-24

$1.49

$

In Stock, only 3 left!

0

24

Gravely 03640100

Extension-Chute

$50.99

$

Usually ships in 4-12 days

0

25

Gravely 53504600

40-In. Service Vane Package

$52.99

$

Usually ships in 4-12 days

0

25

Gravely 035832

(Gravely Part Number)
(Superseded to 53504600)

Note: (Gravely Part Number)

$52.99

$

Usually ships in 4-12 days

0

26

Gravely 05970500

Bolt-Hex .31-24 x .75 Grade 8
(Superseded to 05902019)

$2.49

$

Usually ships in 4-12 days

0

27

05350460

40-In. Vane

$

$

Not available

28

Gravely 06537000

Nut-Center-Lock .31-24

$1.49

$

In Stock, only 3 left!

0

29

Gravely 03599600

Upper Bagger Boot

$

$

Not available

30

Gravely 03026800

Tube
(Superseded to 04222800)

$95.99

$

In Stock, only 2 left!

0

31

Gravely 02770200

Hose Clamp

$45.99

$

Usually ships in 4-12 days

0
