834035 - Gravely 40" Sno-Thro for GEM Tractor (SN: 000101 & Above) Gear Case Parts Diagram

40" Sno-Thro for GEM Tractor

Gear Case Parts Diagram

  • Title

1

Gravely 036868

FAN - 14", BLACK
(Superseded to 02437651)

$287.99

$

Usually ships in 4-12 days

0

2

Gravely 036869

PIN-ROLL .313X1.75
(Superseded to 05801500)

$2.99

$

In Stock, only 2 left!

0

3

Gravely 036851

WORM SHAFT
(Superseded to 03519400)

$218.99

$

Usually ships in 4-12 days

0

4

Gravely 06600800

KEY-WDRF .25X.875X.375 SAE A

$3.99

$

In Stock, only 2 left!

0

5

Gravely 036230

KEY-SQ .188X1.0X.188 SAE 8630
(Superseded to 06601300)

$1.99

$

In Stock, only 1 left!

0

6

Gravely 036855

ADJUSTMENT PLUG - 1" SHAFT
(Superseded to 02401500)

$94.99

$

Usually ships in 4-12 days

0

7

Gravely 036854

SEAL 1.000X1.312X.150
(Superseded to 05606100)

$13.99

$

In Stock, only 2 left!

0

8

Gravely 018445

BRG-CUP 1.781X.475
(Superseded to 05404400)

$11.99

$

In Stock, Qty 17

0

9

Gravely 018446

BRG-CONE .750X.61
(Superseded to 05404500)

$29.99

$

In Stock, Qty 20+

0

10

Gravely 036852

BSHG, SPCR .755X1.12X.50 PM
(Superseded to 00200500)

$7.49

$

In Stock, Qty 7

0

11

Gravely 036858

WORM & GEAR SERVICE ASSEMBLY
(Superseded to 52400900)

$180.99

$

In Stock, only 1 left!

0

12

Gravely 036921

RG-RTNG-INT 1.781X.062
(Superseded to 05707500)

$9.99

$

In Stock, Qty 7

0

13

Gravely 036920

GEAR CASE - CAST IRON
(Superseded to 02400200)

$

$

Not available

14

Gravely 036863

SEAL 1.625X2.125X.250
(Superseded to 05607000)

$10.99

$

In Stock, only 2 left!

0

15

Gravely 035945

PIPE PLUG
(Superseded to 00113800)

$6.49

$

Usually ships in 4-12 days

0

16

Gravely 05947000

BLT-HEX .31-18X.75 GR5 YWZC
(Superseded to 05901704)

$1.99

$

In Stock, Qty 20+

0

17

Gravely 06308600

WSHR-LK .31X.078 REG YWZC
(Superseded to 06300119)

$1.49

$

In Stock, Qty 20+

0

18

Gravely 06437500

WSHR-FL-STL .328X1.0X.094 YWZC
(Superseded to 06401027)

$3.99

$

In Stock, only 2 left!

0

19

Gravely 036856

DUST CAP
(Superseded to 00403700)

$18.99

$

In Stock, only 2 left!

0

20

Gravely 03340300

SHAFT, RAKE - 40"

Note: (Model 834033)

$56.99

$

Usually ships in 4-12 days

0

Gravely 036864

SHAFT, 36" RAKE - 1.00 DIA.
(Superseded to 03519500)

Note: (Model 836010)

$

$

Not available

21

Gravely 05803000

PIN-ROLL .188X1.50

$1.49

$

In Stock, only 4 left!

0

22

Gravely 036860

BSHG-FLG .683X1.87X1.68X2.250
(Superseded to 05505900)

$15.99

$

In Stock, only 2 left!

0

23

Gravely 036859

WSHR-FL-STL 1.625X2.500X.012
(Superseded to 06408700)

$11.99

$

In Stock, only 2 left!

0

24

Gravely 036857

GEAR CASE SHAFT
(Superseded to 02406400)

$184.99

$

Usually ships in 4-12 days

0

25

Gravely 036862

GASKET
(Superseded to 00200800)

$3.99

$

In Stock, Qty 8

0

26

Gravely 036861

GEAR CASE COVER
(Superseded to 02401300)

$139.99

$

Usually ships in 4-12 days

0

27

Gravely 06306800

WSHR-LK-EXT.262X.502X.026YWZC
(Superseded to 06300118)

$0.99

$

In Stock, Qty 10

0

28

Gravely 05946800

BLT-HEX .25-20X.75 GR5 YWZC
(Superseded to 05901716)

$1.49

$

In Stock, only 3 left!

0

29

Gravely 00008000

ARIENS 16 OZ.BOTTLE OF L2 LUBE
(Superseded to 00068800)

$18.99

$

In Stock, Qty 9

0
