86-48SX01 - Toro 48" Snow Thrower Attachment (1978) SNOWTHROWERS-48 IN. (122 CM) Parts Diagram

48" Snow Thrower Attachment

SNOWTHROWERS-48 IN. (122 CM) Parts Diagram

  • Title
1

Toro 251171

Mounting Plate

$

$

Not available

2

Toro 251212

Rollpin

$

$

Not available

3

Toro 251170

Locking Pin

$

$

Not available

4

Toro 251081

Spring

$

$

Not available

5

$

$

Not available

6

Toro 251238

Hydraulic Cylinder

$

$

Not available

7

Toro 251075

FITTING

$

$

Not available

8

Toro 251076

Hydraulic Hose

$

$

Not available

9

Toro 251074

DUST CAP

$

$

Not available

10

Toro 251078

Coupling Plug

$

$

Not available

11

Toro 251073

Q.D. Fitting

$

$

Not available

12

Toro 251072

Dust Cap

$

$

Not available

13

Toro 251166

Mounting Plate

$

$

Not available

14

$

$

Not available

15

Toro 251077

Fitting

$

$

Not available

16

Toro 250030

RING SEAL

$

$

Not available

17

$

$

Not available

18

$

$

Not available

19

Toro 250037

JOINT (CONSISTS 2 PT

$

$

Not available
