Parts Home > Gravely > Accessories & Attachments > 895022 - Gravely Reel Mower Attachment for PM 320 (SN: 000101 & Above) > Deck, Pump & Belts

895022 - Gravely Reel Mower Attachment for PM 320 (SN: 000101 & Above)

Reel Mower Attachment for PM 320

895022 - Gravely Reel Mower Attachment for PM 320 (SN: 000101 & Above) > Parts Diagrams (6) > Deck, Pump & Belts

  • Title
00587200

1

PUMP

Part# 00587200

OEM Warranty Repair Part for Gravely

Usually leaves our warehouse in 5 to 11 business days

Your price: $999.13

02852551

2

BRACKET, HYDROSTAT CONTROL ROD

Part# 02852551

OEM Warranty Repair Part for Gravely

Not available

02852600

3

KNOB

Part# 02852600

OEM Warranty Repair Part for Gravely

Not available

06400532

4

FLAT WASHER, 1/4"

Part# 06400532

OEM Warranty Repair Part for Gravely

Not available

02852700

5

THREADED ROD, 1/4-28

Part# 02852700

OEM Warranty Repair Part for Gravely

Not available

01670900

6

SWITCH COVER

Part# 01670900

OEM Warranty Repair Part for Gravely

Not available

01668500

7

SWITCH, DOUBLE POLE

Part# 01668500

OEM Warranty Repair Part for Gravely

Not available

03722751

8

PLATE, SWITCH

Part# 03722751

OEM Warranty Repair Part for Gravely

Not available

03723100

9

BLOCK, MANIFOLD

Part# 03723100

OEM Warranty Repair Part for Gravely

Not available

03721800

10

BELT, DRIVE

Part# 03721800

OEM Warranty Repair Part for Gravely

Not available

03722551

11

SHEAVE, PUMP

Part# 03722551

OEM Warranty Repair Part for Gravely

Not available

03396451

12

IDLER SUPPORT - PULLEY

Part# 03396451

OEM Warranty Repair Part for Gravely

Not available

03396651

13

IDLER ARM - PUMP

Part# 03396651

OEM Warranty Repair Part for Gravely

Not available

06611300

14

KEY, SQUARE 5 X 5 X 30 MM PLAIN

Part# 06611300

OEM Warranty Repair Part for Gravely

Usually leaves our warehouse in 5 to 11 business days

Your price: $2.18

08300321

15

SPRING, PUMP IDLER

Part# 08300321

OEM Warranty Repair Part for Gravely

Not available

07000916

16

GREASE FITTING, 1/4-28

Part# 07000916

OEM Warranty Repair Part for Gravely

Not available

07300301

17

PULLEY - IDLER

Part# 07300301

OEM Warranty Repair Part for Gravely

Usually leaves our warehouse in 5 to 11 business days

Your price: $39.07

05969800

18

HHCS, M6 X 1.0 X 12

Part# 05969800

OEM Warranty Repair Part for Gravely

Usually leaves our warehouse in 5 to 11 business days

Your price: $1.40

06300034

19

LOCK WASHER, 1/4

Part# 06300034

OEM Warranty Repair Part for Gravely

Usually leaves our warehouse in 5 to 11 business days

Your price: $3.30

06300025

20

FLAT WASHER, 3/8 HARDENED

Part# 06300025

OEM Warranty Repair Part for Gravely

Not available

06500517

21

HEXNUT, 3/8-16 NYLOCK

Part# 06500517

OEM Warranty Repair Part for Gravely

Not available

05900624

22

HHCS, 3/8-16 X 2

Part# 05900624

OEM Warranty Repair Part for Gravely

Not available

05900703

23

HHCS,1/2-13 X 1-1/2 GR5

Part# 05900703

OEM Warranty Repair Part for Gravely

Usually leaves our warehouse in 5 to 11 business days

Your price: $3.30

06400416

24

FLATWASHER,1/2

Part# 06400416

OEM Warranty Repair Part for Gravely

Usually leaves our warehouse in 5 to 11 business days

Your price: $3.30

06500612

25

HEX NUT, 1/2-13

Part# 06500612

OEM Warranty Repair Part for Gravely

Usually leaves our warehouse in 5 to 11 business days

Your price: $3.30

05900621

26

HHCS, 5/16-18 X 1

Part# 05900621

OEM Warranty Repair Part for Gravely

Not available

06500512

27

HEXNUT, 5/16-18 NYLOCK

Part# 06500512 (Superseded to 06500820)

OEM Warranty Repair Part for Gravely

Usually leaves our warehouse in 1 business day

Your price: $1.85

06400509

28

FLATWASHER, 5/16

Part# 06400509 (Superseded to 06437200)

OEM Warranty Repair Part for Gravely

Usually leaves our warehouse in 1 business day

Your price: $1.85

06500540

29

HEXNUT 1/4-28 NYLOCK

Part# 06500540

OEM Warranty Repair Part for Gravely

Not available

05900618

30

HHCS, 1/4-20 X 3/4

Part# 05900618

OEM Warranty Repair Part for Gravely

Not available

07400028

31

PAN HD PHIL MACH SCREW, 10-32 X 1/2

Part# 07400028

OEM Warranty Repair Part for Gravely

Not available

06536000

32

HEX NUT, 10-24 NYLOCK

Part# 06536000

OEM Warranty Repair Part for Gravely

Not available

06700120

33

COTTER PIN, 3/16 X 1-1/2

Part# 06700120

OEM Warranty Repair Part for Gravely

Not available

06400425

34

FLAT WASHER, 3/4" SAE

Part# 06400425

OEM Warranty Repair Part for Gravely

Usually leaves our warehouse in 5 to 11 business days

Your price: $3.30

06100126

35

PAN HD PHIL MACH SCREW, 10-24 X 3/4

Part# 06100126

OEM Warranty Repair Part for Gravely

Not available

03727900

36

CLEVIS PIN, 1/4 DIA X 3/4

Part# 03727900

OEM Warranty Repair Part for Gravely

Not available

06700035

37

COTTER PIN, 3/32 X 1/2

Part# 06700035

OEM Warranty Repair Part for Gravely

Not available

02222100

38

HEX SOC HD CP SC 10-32 X 2

Part# 02222100

OEM Warranty Repair Part for Gravely

Not available

06500322

39

FHN #10-32 KEPS

Part# 06500322

OEM Warranty Repair Part for Gravely

Not available

06000117

40

SET SCREW, 1/4-20 X 1/2

Part# 06000117

OEM Warranty Repair Part for Gravely

Not available

03732100

41

ROD END (INCLUDES ITEMS 36 AND 37)

Part# 03732100

Note: (INCLUDES ITEMS 36 AND 37)

OEM Warranty Repair Part for Gravely

Not available

02290200

42

FENDER WASHER 1/4"

Part# 02290200

OEM Warranty Repair Part for Gravely

Not available

06500523

43

SERRATED FLG NUT 1/4-20

Part# 06500523

OEM Warranty Repair Part for Gravely

Not available

21544026

44

FAN KIT, HYDRO GEAR

Part# 21544026

Note: NOT SHOWN

OEM Warranty Repair Part for Gravely

Usually leaves our warehouse in 5 to 11 business days

Your price: $29.94
