895401 (FP-3132) - Gravely Tow-Behind Finishing Mower (SN: 000101 & Above) Transport Locks Parts Diagram

Tow-Behind Finishing Mower

Transport Locks Parts Diagram

  • Title

1

Gravely 02897900

SPRING; EXTENSION 94375

$

$

Not available

2

Gravely 02247151

WING LOCK WLDMNT, RH 50018540

$

$

Not available

Gravely 02247251

WING LOCK WLDMNT; LH 50018541

$

$

Not available

3

Gravely 06700105

COTTER PIN 5/32 X 1-1/2

$

$

Not available

4

Gravely 02896500

PIN 94331

$

$

Not available

5

Gravely 02238000

CHAIN W/SLEEVE 50017303

$

$

Not available

6

Gravely 02882300

PIN 84672

$

$

Not available

7

Gravely 02106400

PIN PRESTO SPRING CLIP 1273

$

$

Not available

8

Gravely 05900824

HEX HD CPSC 3/8-16 X 1-1/2

$

$

Not available

9

Gravely 06500610

HEX NUT 3/8-16 CP 8151200

$

$

Not available

10

Gravely 06300030

LOCKWASHER 3/8 CP PG 3/8 15812

$

$

Not available

11

Gravely 02248451

HANDLE WELDMENT 50018562

$

$

Not available

12

Gravely 02625551

HOOK; REAR DECK LOCKI 50024037

$

$

Not available

13

Gravely 05700120

SPRING SNAP 94862

$

$

Not available

14

Gravely 06200106

CARR BOLT 3/8 X 2-1/4 5161222

$

$

Not available

15

Gravely 02250100

PIN 50018623

$

$

Not available

16

Gravely 05900931

HEX HD CPSC 3/8-16 X 1-3/4

$

$

Not available

17

Gravely 02091800

JAM NUT 3/8-16 10151200

$

$

Not available

18

Gravely 06400421

FLATWASHER 3/8 USS ZP 15915

$

$

Not available

19

Gravely 05900623

HHCS 3/8-16 X 1-1/4 G5 1161212

$

$

Not available

20

Gravely 02897800

PIN 94374

$

$

Not available
