895412 - Gravely Walker Sprayer (SN: 000101 & Above) Frame And Mast Walking Boom Parts Diagram

Walker Sprayer

Frame And Mast Walking Boom Parts Diagram

  • Title

1

Gravely 02620000

SPRING STRAP 50023876

$

$

Not available

2

Gravely 06500517

HEX NUT 3/8-16 CP NYLOCK 44601

$

$

Not available

3

Gravely 05900618

HEX HD CPSC 1/4-20 X 3/4

$

$

Not available

4

Gravely 08300413

SPRING COMP. .938 O 50023877

$

$

Not available

5

Gravely 02621600

BOOM TUBE 50023909

$

$

Not available

6

Gravely 02587800

CAP 1.00IN SQ. TUBE 50022801

$

$

Not available

7

Gravely 05901030

HEX HD CPSC 3/8-16 X 6 G 44634

$

$

Not available

8

Gravely 06500523

SRATD FLNG HEX NUT 1/4-20 CP

$

$

Not available

9

Gravely 02619500

BOOM ARM TUBE WELDME 50023871

$

$

Not available

10

Gravely 05900808

HEX HD CPSC 1/4-20 X 1-3/4

$

$

Not available

11

Gravely 02619900

AXLE WELDMENT 50023875

$

$

Not available

12

Gravely 02621700

BRACE 50023910

$

$

Not available

13

Gravely 05900822

HHCS 1/2-13 X 3-1/2 G5

$

$

Not available

14

Gravely 06400422

FLATWASHER 1/2 USS ZP 15916

$3.99

$

Usually ships in 4-12 days

0

15

Gravely 07100613

WHEEL & TIRE 12.00 50023920

$

$

Not available

16

Gravely 15554

Nut, 1/2-13, Serrated Flanged Hex

$

$

Not available

17

Gravely 02618853

CENTER HANDLE WELDMENT

$

$

Not available

18

Gravely 05901110

HEX HD CPSCR 1/2-13 X 4 44833

$

$

Not available

19

Gravely 02621800

TUBE LEG 50023911

$

$

Not available

20

Gravely 05900801

HHCS 3/8-16 X 1 G5 20034
(Superseded to 05901711)

$1.99

$

In Stock, Qty 20+

0

21

Gravely 06400423

FLATWASHER 1/4 ZP D STD 15918

$

$

Not available
