895804 - Parker Trailette Sweeper (SN: 000101 & Above) Frame Assembly Parts Diagram

Trailette Sweeper

Frame Assembly Parts Diagram

  • Title

1

Gravely P76-342-C

Plate, Adjuster

$

$

Not available

2

Gravely 04440051

Frame Support, Lower

$

$

Not available

3

Gravely 04439651

Frame Support, Upper

$

$

Not available

4

Gravely P55-160-A

Spacer, .500 OD X .625 L

$

$

Not available

5

Gravely P73-71-A

Wing Nut

$

$

Not available

6

Gravely P76-341-A

Rod Pivot, 43-1/8

$

$

Not available

7

Gravely P76-81-B

Plate, Caster

$9.99

$

Usually ships in 4-12 days

0

8

Gravely P69-111-A

Bolt, Adjuster 44-5/8

$

$

Not available

9

Gravely P78-130-A

Bearing

$

$

Not available

10

Gravely P76-136-B

Caster Fork

$

$

Not available

11

Gravely P76-58-A

Roller

$

$

Not available

12

Gravely P82-138-B-3

Washer, Area Vac 35 29/64 X 1-3/4 X .134

$7.49

$

Usually ships in 4-12 days

0

13

Gravely 07070115

Bolt, Shoulder Socket 3/8 X 2-3/4

$10.99

$

Usually ships in 4-12 days

0

14

Gravely 05957200

Bolt, Hex .31-18 X 2.00 Gr 5 YWZC
(Superseded to 05901805)

$1.49

$

In Stock, Qty 13

0

15

Gravely 06530200

Nut, Nylok .312-18 YWZC
(Superseded to 06500820)

$0.99

$

Usually ships in 4-12 days

0

16

Gravely 06437200

Washer, Flat Steel .344 X .688 X .065 YWZC
(Superseded to 06401017)

$0.99

$

In Stock, Qty 8

0

17

Gravely 06437300

Washer, Flat Steel .281 X .62 X .065 YWZC
(Superseded to 06401001)

$0.99

$

In Stock, Qty 16

0

18

Gravely P59-77-A

Clamp

$38.99

$

Usually ships in 4-12 days

0

19

Gravely P76-240-A

Bracket, Pivot

$11.99

$

In Stock, only 2 left!

0

20

Gravely P69-416-20

Bolt, Contour Head 1/4-20 X 1.25

$3.99

$

Usually ships in 4-12 days

0

21

Gravely 06308400

Washer, Lock .25 X .062 Reg YWZC
(Superseded to 06401009)

$0.99

$

In Stock, Qty 16

0

22

Gravely 06533200

Nut, Hex .25-20 YWZC
(Superseded to 06500916)

$0.99

$

In Stock, Qty 7

0

23

Gravely P69-416-32

Bolt, Contour Head 1/4-20 X 2.0

$5.99

$

Usually ships in 4-12 days

0

24

Gravely P75-89-A

Nut, Speed 1/4

$4.76

$

In Stock, only 2 left!

0

25

Gravely P76-271-A

Spring, Compression

$3.99

$

In Stock, only 2 left!

0

26

Gravely P76-255-A

Basket Stop Weldment

$39.19

$

Usually ships in 4-12 days

0

27

Gravely 04439851

Frame Support, Upper

$65.99

$

Usually ships in 4-12 days

0

28

Gravely 04439951

Frame Support, Lower

$

$

Not available

29

Gravely P76-272-B

Frame Support, 74-3/8

$

$

Not available

30

Gravely 06319000

Washer, Lock Internal Star 3/8 YWZC

$

$

Not available

31

Gravely 06435900

Washer, Flat Steel .438 X 1.00 X .083 YWZC
(Superseded to 06401008)

$1.49

$

In Stock, only 2 left!

0
