8965-2 - Craftsman 2,400 Watt Portable Generator Cradle No. 77567 Parts Diagram

2,400 Watt Portable Generator

Cradle No. 77567 Parts Diagram

  • Title

1

Briggs & Stratton 73015A

BASE, CRADLE

Note: Contact Generac for quantity required

$

$

Currently unavailable

2

Briggs & Stratton 73011

PANEL, END

Note: Contact Generac for quantity required

$

$

Not available

3

Briggs & Stratton 73008

PANEL, MUFFLER
(Superseded to 7073008YP)

Note: Contact Generac for quantity required

$3.49

$

In Stock, only 1 left!

0

5

Briggs & Stratton 73004

PANEL, RECEPTACLE

Note: Contact Generac for quantity required

$1715.99

$

Usually ships in 2-12 days

0

6

Briggs & Stratton 66817

SWITCH, ENGINE RUN/STOP
(Superseded to 66817GS)

Note: Contact Generac for quantity required

$39.99

$

Usually ships in 2-12 days

0

7

Briggs & Stratton 68759

RECEPTACLE-120 VOLTS AC
(Superseded to 68759GS)

Note: Contact Generac for quantity required

$24.99

$

In Stock, only 2 left!

0

8

Briggs & Stratton 66819

BREAKER, CIRCUIT-20 AMP

Note: Contact Generac for quantity required

$

$

Currently unavailable

9

Briggs & Stratton 66820

BREAKER, CIRCUIT-10 AMP

Note: Contact Generac for quantity required

$

$

Not available

10

Briggs & Stratton 6720730

RECEPTACLE-12 VOLTS DC

Note: Contact Generac for quantity required

$

$

Currently unavailable

13

Briggs & Stratton 56893

SCREW, NO. 8032 x 3/8"
(Superseded to 56893GS)

Note: Contact Generac for quantity required

$3.49

$

In Stock, only 1 left!

0

14

Briggs & Stratton 68450

COVER, HANDLE

Note: Contact Generac for quantity required

$

$

Currently unavailable

15

Briggs & Stratton 69661

TANK, FUEL-2.34 U.S. GALLONS

Note: Contact Generac for quantity required

$

$

Not available

16

Briggs & Stratton 69058

CAP, FUEL FILL

Note: Contact Generac for quantity required

$

$

Currently unavailable

17

Briggs & Stratton 64680B

COVER, SPARK PLUG ACCESS
(Superseded to 64680BGS)

Note: Contact Generac for quantity required

$7.99

$

Usually ships in 2-12 days

0

18

Briggs & Stratton 66391B

INDICATOR, FUEL LEVEL

Note: Contact Generac for quantity required

$

$

Not available

19

Briggs & Stratton 71394

CABLE, BATTERY CHARGE
(Superseded to 71394GS)

Note: Contact Generac for quantity required

$42.99

$

Usually ships in 2-12 days

0

20

Briggs & Stratton 73013B

DECAL-RECEPTACLE PANEL

Note: Contact Generac for quantity required

$

$

Currently unavailable

21

Briggs & Stratton 72275

CRADLE, ENGINE END

Note: Contact Generac for quantity required

$

$

Currently unavailable

22

Briggs & Stratton 72276

CRADLE, GENERATOR END
(Superseded to 7072276YP)

Note: Contact Generac for quantity required

$62.99

$

Usually ships in 2-12 days

0

23

Briggs & Stratton 26656

PLATE, DATA

Note: Contact Generac for quantity required

$

$

Currently unavailable

24

Briggs & Stratton 36261

RIVET, DATA PLATE

Note: Contact Generac for quantity required

$

$

Not available

26

Briggs & Stratton 66824

DECAL-CAUTION

Note: Contact Generac for quantity required

$

$

Currently unavailable

27

Briggs & Stratton 70365C

DECAL-START DATA

Note: Contact Generac for quantity required

$

$

Currently unavailable

29

Briggs & Stratton 58443

SCREW, 1/4"-20 x 3/8"
(Superseded to 58443GS)

Note: Contact Generac for quantity required

$3.49

$

Usually ships in 2-12 days

0

30

Briggs & Stratton 68831

RIVET, 4MM

Note: Contact Generac for quantity required

$

$

Currently unavailable

31

Briggs & Stratton 29084

DECAL-U.S.D.A.

Note: Contact Generac for quantity required

$

$

Currently unavailable

32

Briggs & Stratton 70630

FILTER, FUEL

Note: Contact Generac for quantity required

$

$

Currently unavailable

33

Briggs & Stratton 72094

SHIELD, FUEL TANK HEAT
(Superseded to 7072094YP)

Note: Contact Generac for quantity required

$18.99

$

Usually ships in 2-12 days

0

35

Briggs & Stratton 52749

SCREW, M5-0.80 x 12MM

Note: Contact Generac for quantity required

$

$

Currently unavailable

36

Briggs & Stratton 23963

SCREW, NO. 10-32 x 3/4"
(Superseded to 593696)

Note: Contact Generac for quantity required

$25.99

$

In Stock, only 4 left!

0

39

Briggs & Stratton 73054

DECAL-FUEL SHUT-OFF

Note: Contact Generac for quantity required

$

$

Not available

40

Briggs & Stratton 23365

LOCKWASHER-INTERNAL SHAKEPROOF
(Superseded to 5023365)

Note: Contact Generac for quantity required

$462.99

$

In Stock, only 2 left!

0

41

Briggs & Stratton 22264

LOCKWASHER-NO. 8

Note: Contact Generac for quantity required

$

$

Not available

42

Briggs & Stratton 36917

SCREW, NO. 8-32 x 3/8"
(Superseded to 797483)

Note: Contact Generac for quantity required

$4.49

$

Usually ships in 2-12 days

0

43

Briggs & Stratton 22471

NUT, HEX-NO. 8-32
(Superseded to 22471GS)

Note: Contact Generac for quantity required

$3.99

$

Usually ships in 2-12 days

0

Briggs & Stratton 77561

MANUAL, OWNERS

Note: Contact Generac for quantity required

$

$

Currently unavailable

44

Briggs & Stratton 73745

PANEL, BRACE
(Superseded to 7073745YP)

Note: Contact Generac for quantity required

$12.99

$

Usually ships in 2-12 days

0

45

Briggs & Stratton 25433

GROUND LUG

Note: Contact Generac for quantity required

$

$

Not available
