915050 (ZT 2352) - Gravely 52" Zero-Turn Mower, 23hp Kohler (SN: 005000 - 009999) Mower Deck Lift Parts Diagram

52" Zero-Turn Mower, 23hp Kohler

Mower Deck Lift Parts Diagram

  • Title

1

Gravely 00270200

Rod, Lift

$26.99

$

Usually ships in 4-12 days

0

2

Gravely 00186200

Weldment, Front Lift

$74.99

$

Usually ships in 4-12 days

0

3

Gravely 01592200

Bushing, Front

$

$

Not available

4

Gravely 036872

Bushing-Flange 1.00 x 1.12 x .62 x 1.50 Bronze
(Superseded to 05503500)

$12.99

$

In Stock, Qty 18

0

5

Gravely 00182851

Bracket, Front Pivot

$

$

Not available

6

Gravely 00175851

Bracket, Rear Pivot

$18.99

$

Usually ships in 4-12 days

0

7

Gravely 01591800

Bushing, Rear

$3.99

$

Usually ships in 4-12 days

0

8

Gravely 01591700

Weldment, Lift, Rear Right Hand

$45.99

$

Usually ships in 4-12 days

0

9

Gravely 01591600

Weldment, Lift, Rear Left Hand

$51.99

$

Usually ships in 4-12 days

0

10

Gravely 00161600

Weldment, Foot Pedal

$

$

Not available

11

Gravely 06441900

Washer-Flat-Steel .531 x 1.06 x .095
(Superseded to 06401015)

$0.99

$

In Stock, Qty 20+

0

12

Gravely 05963300

Bolt, Hex .38-16 x 2.00 Grade 5
(Superseded to 05901718)

$2.99

$

In Stock, Qty 13

0

13

Gravely 06545500

Nut .38-16 Flange Nyloc
(Superseded to 06500726)

$1.49

$

In Stock, Qty 20+

0

14

Gravely 06714900

Pin, Hair External

$0.99

$

In Stock, Qty 18

0

15

Gravely 06224400

Bolt, Round Head Square Neck .38-16 x 2.50 Grade 5
(Superseded to 06200234)

$3.99

$

In Stock, only 2 left!

0

16

Gravely 05716800

Ring, Retaining .82 x 1.50 x .05

$2.49

$

In Stock, only 4 left!

0

17

Gravely 01593500

Pin, Spring Ball .375 O.D. x 1.50

$5.99

$

In Stock, only 2 left!

0

18

Gravely 00182251

Bracket, Rear Mount

$11.99

$

Usually ships in 4-12 days

0

19

Gravely 07411600

Screw-Tapping .250-20 x .37 Hex Washer Head
(Superseded to 07400125)

$0.99

$

In Stock, Qty 6

0

20

Gravely 06927100

Cable, Hood

$14.99

$

Usually ships in 4-12 days

0

21

Gravely 00165000

Tube, Lift Stop

$

$

Not available

22

Gravely 00165100

Rod, Lift

$

$

Not available

23

Gravely 07000004

Bolt, Socket Head Screw .31 x 18 2.25

$

$

Not available

24

Gravely 06545400

Nut, .312-18 Flange Nyloc
(Superseded to 06500809)

$1.49

$

In Stock, Qty 15

0

25

Gravely 00182500

Spacer, Rear Lift

$5.99

$

Usually ships in 4-12 days

0

26

Gravely 06542000

Nut-Locking-Top-Flange .38-16
(Superseded to 06500822)

$1.49

$

In Stock, Qty 20+

0

27

Gravely 06444300

Washer-Flat-Steel .390 x .75 x.125

$7.99

$

In Stock, Qty 9

0

28

Gravely 06445300

Washer-Flat Steel 1.12 x 1.50 x .092

$2.99

$

Usually ships in 4-12 days

0
