915095 (2250) - Ariens Zoom 50" Zero-Turn Mower, 22hp Kohler (SN: 000101 & Above) Fuel Tank Parts Diagram

Zoom 50" Zero-Turn Mower, 22hp Kohler

Fuel Tank Parts Diagram

  • Title

1

Ariens 00479500

GAS TANK, ZOOM

$

$

Not available

2

Ariens 01538400

FUEL CAP

$16.99

$

Usually ships in 4-12 days

0

3

Ariens 09112300

FITTING, TANK
(Superseded to 03875300)

$15.99

$

In Stock, only 1 left!

0

4

Ariens 07511400

BSHG-FLG .375 X 1.062 X .625 R

$3.99

$

In Stock, Qty 11

0

5

Ariens 05948000

@BLT-HEX .31-18X3.50 GR5 YWZC

$2.99

$

Usually ships in 4-12 days

0

6

Ariens 06435700

@WSHR-FL-STL.38X.875X.083 YWZC
(Superseded to 06401023)

$1.99

$

In Stock, Qty 6

0

7

Ariens 00480900

SPCR, FLG .32X.49X.15X2.64

$21.99

$

Usually ships in 4-12 days

0

8

Ariens 05947000

@BLT-HEX .31-18X.75 GR5 YWZC
(Superseded to 05901704)

$1.99

$

In Stock, Qty 20+

0

9

Ariens 01305900

BSHG, FLG .325X.499X.26X.88

$2.49

$

In Stock, only 4 left!

0

10

Ariens 00619600

THROTTLE/CHOKE CABLE

$65.99

$

In Stock, only 2 left!

0

11

Ariens 06545400

@NUT-LK-NYL-FLG .31-18 YWZC
(Superseded to 06500809)

$1.99

$

In Stock, Qty 20+

0

12

Ariens 00479600

FENDER, ZOOM

$

$

Not available

13

Ariens 00605000

CABLE, THROTTLE
(Superseded to 00581700)

Note: (915085)

$59.99

$

Usually ships in 4-12 days

0

14

Ariens 01588300

KEY SWITCH

$33.99

$

In Stock, only 3 left!

0

15

Ariens 02460700

KEY -W/CAP

$10.99

$

In Stock, Qty 20+

0

16

Ariens 01545600

SWITCH, CLUTCH

$27.99

$

In Stock, Qty 11

0

17

Ariens 07415800

@SCR-TAP 10-24X.50 HWH TR YWZC
(Superseded to 07400130)

$2.49

$

In Stock, Qty 5

0

17

Ariens 07415800

@SCR-TAP 10-24X.50 HWH TR YWZC
(Superseded to 07400130)

$2.49

$

In Stock, Qty 5

0

18

Ariens 00603651

CONTROL PANEL

$

$

Not available

19

Ariens 06830000

RIVET, PLASTIC .195 DIA.

$2.49

$

In Stock, Qty 10

0
