921026 - Gravely 28" Power Brush, Subaru (SN: 057000 & Above) Brush Head Parts Diagram

28" Power Brush, Subaru

Brush Head Parts Diagram

  • Title

1

Gravely 00180600

SPROCKET, REDUCTION IDLER

$158.99

$

Usually ships in 4-12 days

0

2

Gravely 00180853

MOUNT, REDUCTION IDLER

$15.99

$

Usually ships in 4-12 days

0

3

Gravely 00181200

SHAFT, 28" BRUSH

$85.99

$

Usually ships in 4-12 days

0

4

Gravely 00368500

CHAIN, #40-54 LINKS

$31.99

$

Usually ships in 4-12 days

0

5

Gravely 00386100

CHAIN, #41-50 LINKS

$31.99

$

Usually ships in 4-12 days

0

6

Gravely 00428700

BEARING FLANGE

$19.99

$

In Stock, Qty 11

0

7

Gravely 02997400

SPROCKET, DRIVE

$92.99

$

Usually ships in 4-12 days

0

8

Gravely 02997500

SPROCKET, DRIVEN

$127.99

$

Usually ships in 4-12 days

0

9

Gravely 03278451

FRAME, POWER BROOM-DELUXE

$329.99

$

Usually ships in 4-12 days

0

10

Gravely 00180100

BRUSH, 18"DIA X 28"WIDE

$593.99

$

Usually ships in 4-12 days

0

11

Gravely 01014200

BEARING FLANGE

$6.49

$

In Stock, Qty 20+

0

12

Gravely 02997600

SHAFT, TRANSMISSION

$40.99

$

Usually ships in 4-12 days

0

13

Gravely 03634600

SPACER .755X1.250X.370

$8.49

$

Usually ships in 4-12 days

0

14

Gravely 05406300

BRG-BALL .750X1.750X.50

$27.99

$

In Stock, Qty 20+

0

15

Gravely 05480000

BRG-BALL .50X1.38X.438 SEALED

$15.99

$

In Stock, Qty 20+

0

16

Gravely 05714600

RG-RTNG-EXT .689X.078

$2.99

$

In Stock, only 4 left!

0

17

Gravely 05964700

@BLT-HEX .25-20X1.75 GR5 YWZC
(Superseded to 05901935)

$2.49

$

In Stock, Qty 5

0

18

Gravely 06400828

WSHR-FL-STL .536X1.07X.109 YZ

$2.99

$

Usually ships in 4-12 days

0

19

Gravely 06543500

@NUT-LK-TOP-FLG .25-20 YWZC
(Superseded to 06500903)

$1.49

$

In Stock, Qty 20+

0

20

Gravely 06600300

KEY-WDRF .188X.75X.313 SAE 9

$1.49

$

In Stock, only 4 left!

0

21

Gravely 07400034

SCR-TAP .25-20X.50 HWH TR YWZ
(Superseded to 07400122)

$0.99

$

In Stock, Qty 20+

0
