986003 - Gravely Pressure Washer (SN: 002001 & Above) Pump And Valves 3GTX27 Parts Diagram

Pressure Washer

Pump And Valves 3GTX27 Parts Diagram

  • Title

1

Gravely 20000531

PUMP ASSEMBLY
(Superseded to 20003026)

Note: (Inc. Key Nos. 2-9 and 11-20)

$

$

Not available

2

Gravely 20000490

BUBBLE OIL GAUGE W/GASKET

$47.99

$

Usually ships in 4-12 days

0

3

Gravely 20000491

SEAL KIT

$355.99

$

Usually ships in 4-12 days

0

4

Gravely 20000492

O-RING KIT

$34.99

$

Usually ships in 4-12 days

0

5

Gravely 20000493

VALVE KIT

Note: (Set of 3)

$

$

Not available

6

Gravely 20000494

CHEMICAL INJECTOR

$215.99

$

Usually ships in 4-12 days

0

7

Gravely 20000495

CHECK VALVE SEAT

$

$

Not available

8

Gravely 20000496

CHECK VALVE W/O-RING

$

$

Not available

9

Gravely 20000497

VENT CAP (CAT)
(Superseded to 20000510)

Note: (CAT)

$

$

Not available

10

Gravely 20000498

TUBE (OPTIONAL 11 IN.)

Note: (Optional, 11 in.)

$3.99

$

Usually ships in 4-12 days

0

11

Gravely 20000499

DRAIN PLUG

$

$

Not available

12

Gravely 20000501

PLUG

$

$

Not available

13

Gravely 20000502

UNLOADER ASSEMBLY

Note: (Inc. Key No. 4)

$

$

Not available

14

Gravely 20000503

O-RING

$

$

Not available

15

Gravely 20000504

SPRING

$8.99

$

Usually ships in 4-12 days

0

16

Gravely 20000505

O-RING

$

$

Not available

17

Gravely 20000506

BOLT

Note: (M6)

$

$

Not available

18

Gravely 20000507

O-RING

$11.99

$

Usually ships in 4-12 days

0

19

Gravely 20000508

OIL SEAL

$

$

Not available

20

Gravely 20000509

OIL SEAL

$

$

Not available

21

Gravely 20000510

VENT CAP (OPTIONAL)

Note: (Optional)

$

$

Not available
