986052 - Gravely 7500 Watt Generator (SN: 010000 & Above) Voltage Regulator Parts Diagram

7500 Watt Generator

Voltage Regulator Parts Diagram

  • Title

1

Gravely 20000960

ADAPTOR HOUSING

$29.99

$

Usually ships in 4-12 days

0

2

Gravely 20000967

BOLT (M5, HEX HD.)

Note: (M5, Hex Hd.)

$3.99

$

Usually ships in 4-12 days

0

3

Gravely 20000952

GENERATOR HEAD COVER

$10.99

$

Usually ships in 4-12 days

0

4

Gravely 20000951

LOCK WASHER (5/16)

Note: (5/16 in.)

$

$

Not available

5

Gravely 20000974

ROTOR BOLT (170 MM)

Note: (170 mm)

$

$

Not available

6

Gravely 20000802

RUBBER BOOT

$3.99

$

Usually ships in 4-12 days

0

7

Gravely 20000989

HEX NUT (M5)

Note: (M5)

$3.99

$

Usually ships in 4-12 days

0

8

Gravely 20000987

BEARING HOUSING

$

$

Not available

9

Gravely 20000933

TERMINAL BLOCK

$

$

Not available

10

Gravely 20000966

BOLT (M5 X 16 MM)

Note: (M5 x 16 mm)

$3.99

$

Usually ships in 4-12 days

0

11

Gravely 20000973

STATOR BOLT (170 MM)

Note: (170 mm)

$

$

Not available

12

Gravely 20000932

BRUSH ASSEMBLY

$15.99

$

Usually ships in 4-12 days

0

13

Gravely 20000770

BONDING WIRE

$

$

Not available

14

Gravely 20000980

BRUSH COVER

$6.99

$

Usually ships in 4-12 days

0

15

Gravely 20000965

BOLT (M5 X 12 MM)

Note: (M5 x 12 mm)

$3.99

$

Usually ships in 4-12 days

0

16

Gravely 20000768

AUTOMATIC VOLTAGE REGULATOR

$134.99

$

Usually ships in 4-12 days

0
