988064 - Gravely Pro 300 Walk-Behind Mower Power Unit, 18hp Kohler (SN: 000101 & Above) HYDRAULIC SYSTEM Parts Diagram

Pro 300 Walk-Behind Mower Power Unit, 18hp Kohler

HYDRAULIC SYSTEM Parts Diagram

  • Title

1

Gravely 187147

Bolt-Hex .31-18 x 3.50
(Superseded to 05948000)

$2.99

$

Usually ships in 4-12 days

0

2

Gravely 053122

Washer, Flat .344 x 3.0 x .060
(Superseded to 08857300)

$

$

Not available

3

Gravely 044877

Cap, Tank
(Superseded to 08826200)

$22.99

$

Usually ships in 4-12 days

0

4

Gravely 053021

Tank, Hydraulic
(Superseded to 08868400)

$

$

Not available

5

Gravely 180077

Bolt-Hex .31-18 x .75 Grade 5
(Superseded to 05901704)

$1.99

$

In Stock, Qty 20+

0

6

Gravely 053121

Bracket, Hydraulic Tank Mounting
(Superseded to 08857200)

$

$

Not available

7

Gravely 419455

Nut-Locking-Nylon .312-18 Grade 2
(Superseded to 06500820)

$1.49

$

In Stock, Qty 20+

0

8

Gravely 053111

Adapter - Male
(Superseded to 07018800)

$

$

Not available

9

Gravely 053105

Hose, Oil Cooler to Tank
(Superseded to 08856600)

$

$

Not available

10

Gravely 021247

Clamp, .88 Diameter Hose
(Superseded to 06923500)

$2.49

$

In Stock, Qty 6

0

11

Gravely 021799

Adapter, Tee, .56-18
(Superseded to 07021500)

$31.99

$

Usually ships in 4-12 days

0

12

Gravely 039847

Hose, Hydraulic Valve to Tank
(Superseded to 08811300)

$40.99

$

Usually ships in 4-12 days

0

13

Gravely 053103

Hose, Pump to Tee
(Superseded to 08856400)

$46.99

$

Usually ships in 4-12 days

0

14

Gravely 046116

Fitting, Elbow, .50 x .50
(Superseded to 07019800)

$

$

Not available

15

Gravely 053099

Cock, Drain, .38 x .69 x 1.25
(Superseded to 07018700)

$25.99

$

Usually ships in 4-12 days

0

16

Gravely 018826

Adapter 2503-4-4
(Superseded to 08800700)

$25.99

$

Usually ships in 4-12 days

0

17

Gravely 180087

Bolt-Hex .31-18 x 2.00 Grade 5
(Superseded to 05901805)

$1.99

$

In Stock, Qty 12

0

18

Gravely 088808

Bushing, Split, .328 x .462 x .75
(Superseded to 08880800)

$3.49

$

Usually ships in 4-12 days

0

19

Gravely 051281

Hose, Oil Filter to Pump
(Superseded to 08845200)

$

$

Not available

20

Gravely 021286

Adapter 0503-4-4
(Superseded to 08801500)

$6.49

$

Usually ships in 4-12 days

0

21

Gravely 050961

Adapter - Pipe .75-16
(Superseded to 07018200)

$7.49

$

Usually ships in 4-12 days

0

22

Gravely 053104

Hose, Tank to Oil Filter
(Superseded to 08856500)

$

$

Not available

23

Gravely 419454

Nut-Locking-Nylon .250-20 Grade 2
(Superseded to 06500832)

$5.49

$

In Stock, only 2 left!

0

24

Gravely 053330

Variable Displace Pump
(Superseded to 09279900)

$1263.99

$

Usually ships in 4-12 days

0

25

Gravely 180123

Bolt-Hex .38-16 x 1.125

$

$

Not available

26

Gravely 120394

Washer-Flat-Steel .406 x .812 x .065
(Superseded to 06401013)

$1.49

$

In Stock, Qty 20+

0

27

Gravely 413534

Nut-Locking-Center .625 - 10 Grade 2
(Superseded to 06500825)

$1.49

$

In Stock, Qty 20+

0

28

Gravely 180044

Bolt-Hex .25-20 x 2.00 Grade 5
(Superseded to 05901740)

$2.99

$

Usually ships in 4-12 days

0

29

Gravely 018828

Adapter 2503-6-6
(Superseded to 00313270)

$9.99

$

Usually ships in 4-12 days

0

30

Gravely 051142

Assembly, Spin-On Lube
(Superseded to 08844700)

$

$

Not available

31

Gravely 051143

Assembly, Head
(Superseded to 08157900)

$

$

Not available

32

Gravely 050968

Element
(Superseded to 08841800)

$39.99

$

Usually ships in 4-12 days

0

33

Gravely 088754

Bracket, Oil Cooler, Recoil
(Superseded to 08897700)

Note: Model (65)

$20.99

$

Usually ships in 4-12 days

0

Gravely 053109

Bracket, Oil Cooler, B & S
(Superseded to 08856900)

Note: Model (19)

$

$

Not available

Gravely 053110

Bracket, Oil Cooler, Kohler
(Superseded to 08857000)

Note: Model (64)

$

$

Not available

34

Gravely 180020

Bolt-Hex .25-20 x .75 Grade 5
(Superseded to 05901716)

$1.49

$

In Stock, Qty 12

0

35

Gravely 053101

Cooler, Oil
(Superseded to 08856200)

$

$

Not available

36

Gravely 051889

Pin-Dowel .312 x 1.25
(Superseded to 05808000)

$6.49

$

Usually ships in 4-12 days

0

37

Gravely 088807

Arm, Pump Actuating
(Superseded to 08880700)

$

$

Not available

38

Gravely 180024

Bolt-Hex .25-20 x 1.25 Grade 5
(Superseded to 05901738)

$2.49

$

In Stock, Qty 7

0

39

Gravely 051232

Assembly, Hose, Wheel Motor to Pump
(Superseded to 58803900)

$171.99

$

Usually ships in 4-12 days

0

40

Gravely 051231

Assembly, Hose, Wheel Motor to Pump
(Superseded to 58803800)

$152.99

$

Usually ships in 4-12 days

0

41

Gravely 091117

Motor, Hydraulic Wheel
(Superseded to 09111700)

$652.99

$

Usually ships in 4-12 days

0

42

Gravely 051106

Bracket, Wheel Motor
(Superseded to 08842400)

$14.99

$

Usually ships in 4-12 days

0

43

Gravely 120382

Washer-Lock .375 x .094
(Superseded to 06300116)

$1.49

$

In Stock, Qty 18

0

44

Gravely 180121

Bolt-Hex .380-16 x .875
(Superseded to 05932600)

$2.99

$

In Stock, only 1 left!

0

45

Gravely 180122

Bolt-Hex .38-16 x 1.00 Grade 5
(Superseded to 05901711)

$1.99

$

In Stock, Qty 20+

0

46

Gravely 456004

Nut-Locking-Nylon .375-16 Grade 2
(Superseded to 06500831)

$3.49

$

In Stock, Qty 20+

0
