989306 (PM 460) - Gravely Pro-Master Zero-Turn Mower, 30hp Kubota (SN: 000101 & Above) Hydraulic Lift Parts Diagram

Pro-Master Zero-Turn Mower, 30hp Kubota

Hydraulic Lift Parts Diagram

  • Title

1

Gravely 07529900

Knob
(Superseded to 07533500)

$9.99

$

In Stock, only 4 left!

0

2

Gravely 06814700

Pin-Clevis .50 x 1.33

$5.99

$

Usually ships in 4-12 days

0

3

Gravely 044950

Rod End. .50-20 Right Hand
(Superseded to 08959600)

$38.99

$

Usually ships in 4-12 days

0

4

Gravely 06712600

Pin-Cotter .12 x 1.25
(Superseded to 06700212)

$0.99

$

In Stock, Qty 8

0

5

Gravely 06539500

Nut-Jam .50-20

$2.49

$

Usually ships in 4-12 days

0

6

Gravely 050679

Cylinder, Lift
(Superseded to 08998900)

$

$

Not available

7

Gravely 06307300

Washer-Lock .50 Regular
(Superseded to 06300115)

$1.49

$

In Stock, Qty 17

0

8

Gravely 018828

Adapter
(Superseded to 00313270)

$9.49

$

In Stock, only 1 left!

0

9

Gravely 052579

Grommet, 1.25
(Superseded to 07536800)

$12.99

$

Usually ships in 4-12 days

0

10

Gravely 09071600

Assembly, Hydraulic Hose

$

$

Not available

11

Gravely 041634

Tie Wrap, Black
(Superseded to 07519900)

$3.49

$

Usually ships in 4-12 days

0

12

Gravely 045291

Fitting-Manifold .38 x 1.50
(Superseded to 07015700)

$

$

Not available

13

Gravely 09236000

Assembly, Hydraulic Hose

$137.99

$

Usually ships in 4-12 days

0

14

Gravely 09083100

Hose, 3/8 inch x 24 inch

$9.49

$

Usually ships in 4-12 days

0

15

Gravely 07017500

Adapter-Pipe

$11.99

$

In Stock, only 2 left!

0

16

Gravely 09067400

Valve

$

$

Not available

17

Gravely 06221600

Bolt-Round Head Square Neck .31-18 x 2.25
(Superseded to 06200408)

$2.99

$

Usually ships in 4-12 days

0

18

Gravely 06529800

Nut-Locking-Center .31-18
(Superseded to 06500826)

$1.49

$

In Stock, Qty 20+

0

19

Gravely 09091700

Control Rod

$

$

Not available

20

Gravely 06537800

Nut-Jam M10-1.5

$

$

Not available

21

Gravely 07051200

Fitting, Adapter

$

$

Not available

22

Gravely 07019500

Adapter, Fitting Tee

$

$

Not available

23

Gravely 07019700

Fitting, Adapter .562-18

$6.99

$

Usually ships in 4-12 days

0

24

Gravely 09083200

Hose, 3/8 inch x 27 inch

$

$

Not available

25

Gravely 06924300

Hose Clamp

$6.99

$

Usually ships in 4-12 days

0

26

Gravely 08856600

Hose, Hydraulic

$

$

Not available

28

UNKNOWN

UNKNOWN

$

$

Not available
