990003 (PM 350) - Gravely Pro-Master Zero-Turn Mower, 21hp Kubota (SN: 000101 & Above) Rear Axle Assembly Parts Diagram

Pro-Master Zero-Turn Mower, 21hp Kubota

Rear Axle Assembly Parts Diagram

  • Title

$

$

Not available

$

$

Not available

$

$

Not available

1

Gravely 09049300

WLDMT, PM-350 STEERING AXLE

$91.99

$

Usually ships in 4-12 days

0

2

Gravely 019340

WSHR-HDND-THRUST 1.00X1.55X.03
(Superseded to 06435300)

$5.49

$

In Stock, Qty 8

0

3

Gravely 018355

BSHG-FLG1.020X1.385X.75X1.75NY
(Superseded to 05520100)

$11.99

$

In Stock, Qty 20+

0

4

Gravely 180181

BLT-HEX .50-13X2.00 GR5 YWZC
(Superseded to 05901929)

$3.49

$

In Stock, only 2 left!

0

5

Gravely 031368

SPACER .516X.875X.300
(Superseded to 09036100)

$37.99

$

Usually ships in 4-12 days

0

6

Gravely 435507

NUT-LK-NYL .50-13 YWZC
(Superseded to 06500830)

$2.99

$

In Stock, Qty 20+

0

7

Gravely 052913

KINGPIN, L.H.
(Superseded to 09006300)

$39.99

$

Usually ships in 4-12 days

0

8

Gravely 05800400

PIN-ROLL .250X1.50

$

$

Not available

9

Gravely 052914

WLDMT,KINGPIN R.H.
(Superseded to 09006400)

$

$

Not available

10

Gravely 044950

ROD END, 1/2 RH
(Superseded to 08959600)

$40.99

$

Usually ships in 4-12 days

0

11

Gravely 09049500

ROD, TIE

$

$

Not available

12

Gravely 09066700

WELDMENT, STEERING AXLE PIN

$

$

Not available

13

Gravely 05948700

BLT-HEX .38-16X1.00 GR5 YWZC
(Superseded to 05901711)

$1.99

$

In Stock, Qty 20+

0

14

Gravely 06529600

NUT-LK-CTR .38-16 YWZC
(Superseded to 06500825)

$1.49

$

In Stock, Qty 20+

0

15

Gravely 06418500

WSHR-FL-STL 1.015X1.500X.125
(Superseded to 06400025)

$6.49

$

Usually ships in 4-12 days

0

16

Gravely 06521300

NUT-LK 1.0-14 WSHR INSERT
(Superseded to 00181818)

$10.99

$

In Stock, only 2 left!

0

17

Gravely 09066800

PLATE

$

$

Not available
