990016 (PM 360) - Gravely Pro-Master Zero-Turn Mower, 22hp Kawasaki (SN: 000101 & Above) REAR AXLE Parts Diagram

Pro-Master Zero-Turn Mower, 22hp Kawasaki

REAR AXLE Parts Diagram

  • Title

1

Gravely 09067700

STEERING AXLE

$

$

Not available

2

Gravely 09076700

WMT, AXLE PIN

$

$

Not available

3

Gravely 07402200

SCR-TAP .375-16X.75 HWH PL TR
(Superseded to 07415400)

$1.99

$

In Stock, Qty 20+

0

4

Gravely 05521400

BSHG-SLV 1.00X1.25X1.25 BR

$

$

Not available

5

Gravely 06436300

WSHR-FL-STL 1.010X1.505X.062YZ
(Superseded to 06401132)

$1.99

$

In Stock, Qty 20+

0

6

Gravely 06538400

NUT-LK 1.0-14 YWZC
(Superseded to 00181818)

$10.99

$

Usually ships in 4-12 days

0

7

Gravely 07012600

FTG-LUBE .25-28X.256 YWZC
(Superseded to 07001806)

$

$

Not available

8

Gravely 09082700

WMT-KINGPIN (LH)

Note: (LH)

$

$

Not available

9

Gravely 06435300

WSHR-HDND-THRUST 1.00X1.55X.03

$5.49

$

In Stock, Qty 8

0

10

Gravely 05520100

BSHG-FLG1.020X1.385X.75X1.75NY

$11.99

$

In Stock, Qty 20+

0

11

Gravely 09082800

WMT-KINGPIN (RH)

Note: (RH)

$

$

Not available

12

Gravely 05800400

PIN-ROLL .250X1.50

$

$

Not available

13

Gravely 08959600

ROD END, 1/2 RH

$40.99

$

Usually ships in 4-12 days

0

14

Gravely 06539500

NUT-JAM .50-20 GR2 YWZC

$2.99

$

Usually ships in 4-12 days

0

15

Gravely 05959700

BLT-HEX .50-13X2.00 GR5 YWZC
(Superseded to 05901929)

$3.49

$

In Stock, only 1 left!

0

16

Gravely 08974800

SPACER .520X.625X.125 ST

$22.99

$

In Stock, only 1 left!

0

17

Gravely 06536300

NUT-LK-CTR .50-13 YWZC
(Superseded to 06500827)

$4.99

$

In Stock, Qty 19

0

18

Gravely 09073400

TIE ROD

$

$

Not available

19

Gravely 09002500

ROD END, 1/2 LH

$

$

Not available

20

Gravely 06538300

NUT-JAM .50-20 LH GR2 YWZC

$

$

Not available

21

Gravely 09062100

SPACER .56X1.00X.420

$5.99

$

Usually ships in 4-12 days

0

22

Gravely 07012800

FTG,LUBE 90 DEG .250-28 TAPER

$5.49

$

In Stock, Qty 5

0
