990101 - Gravely Rapid XZ Zero-Turn Mower, 25hp Kohler (SN: 000101 & Above) Rear Axle and Weights Parts Diagram

Rapid XZ Zero-Turn Mower, 25hp Kohler

Rear Axle and Weights Parts Diagram

  • Title

1

Gravely 00675300

SPACER, FRONT WHEEL

$9.49

$

In Stock, Qty 20+

0

2

Gravely 00456800

CAP, DUST

$18.99

$

In Stock, Qty 8

0

3

Gravely 00475051

WMT, REAR AXLE

$

$

Not available

4

Gravely 00531400

BEARING SEAL 1.5 X 2 X .18

$10.99

$

In Stock, Qty 20+

0

5

Gravely 00531500

SPACER 1.005X1.5075X.375

$8.49

$

In Stock, Qty 13

0

6

Gravely 00607900

SPACER, 1 X 1.50 X 3.16"LG

$47.99

$

Usually ships in 4-12 days

0

7

Gravely 00613300

WMT, REAR AXLE MTG PLATE

$

$

Not available

8

Gravely 00613400

COVER, DUAL REAR AXLE

$

$

Not available

9

Gravely 05517600

BSHG-FLG 1.514X1.756X1.688X2.2

$9.99

$

In Stock, only 4 left!

0

10

Gravely 05978200

BLT-HEX .50-13X7.50 GR5 YWZC
(Superseded to 05902023)

$8.49

$

In Stock, Qty 17

0

11

Gravely 06439000

WSHR-FL-STL.812X1.50X.135YWZC
(Superseded to 06401140)

$1.99

$

In Stock, Qty 20+

0

12

Gravely 06443000

WSHR-FL-STL- 1.062X2.0X.134 YZ
(Superseded to 06401203)

$4.99

$

Usually ships in 4-12 days

0

13

Gravely 06500010

NUT-LK-NYL-FLG .50-13 YWZC
(Superseded to 06500810)

$1.99

$

In Stock, Qty 20+

0

14

Gravely 06536900

NUT-JAM CTRLK .75-16 YWZC

$6.49

$

In Stock, Qty 11

0

15

Gravely 06500022

NUT-LK-NYL 1.0-8 YWZC

$3.99

$

Usually ships in 4-12 days

0

16

Gravely 07012600

FTG-LUBE .25-28X.256 YWZC
(Superseded to 07001806)

$

$

Not available

17

Gravely 07100206

TIRE/WHEEL ASSY 13X5-6
(Superseded to 07101111)

$131.99

$

In Stock, Qty 20+

0

18

Gravely 05959400

BLT-HEX .38-16X.75 GR5 YWZC
(Superseded to 05901702)

$1.99

$

In Stock, Qty 14

0

19

Gravely 00490251

WMT - FORK
(Superseded to 59208400)

$211.99

$

In Stock, only 1 left!

0

20

Gravely 05407000

BRG-CUP1.980X.420

$18.99

$

In Stock, Qty 20+

0

Gravely 69000300

BRG, CONE W/ GREASE
(Superseded to 05406900)

$20.99

$

In Stock, Qty 20+

0

21

Gravely 05900104

BLT-HEX 1.0-8X5.50 GR5 YWZC

$12.99

$

Usually ships in 4-12 days

0

22

Gravely 06223100

BLT-RDHDSQNK .50-13X1.50 G5YZ
(Superseded to 06200421)

$5.49

$

Usually ships in 4-12 days

0

23

Gravely 05978200

BLT-HEX .50-13X7.50 GR5 YWZC
(Superseded to 05902023)

$8.49

$

In Stock, Qty 17

0

24

Gravely 06430200

WSHR-FL-STL .531X1.250X.10 YWZ
(Superseded to 06401128)

$1.49

$

In Stock, Qty 20+

0

25

Gravely 00172000

WEIGHT, CAST IRON

$303.99

$

Usually ships in 4-12 days

0

26

Gravely 07415400

SCR-TAP .38-16X.75 HWH TR YWZ
(Superseded to 07400129)

$1.99

$

In Stock, Qty 20+

0

27

Gravely 00595451

BRKT, WEIGHT (OUTFRONT)

Note: (OUTFRONT)

$51.99

$

Usually ships in 4-12 days

0

28

Gravely 06536300

NUT-LK-CTR .50-13 YWZC
(Superseded to 06500827)

$4.99

$

In Stock, Qty 19

0

29

Gravely 06435700

WSHR-FL-STL.38X.875X.083 YWZC
(Superseded to 06401023)

$1.99

$

In Stock, Qty 20+

0
