991059 (PM 48Z) - Gravely Pro-Master 48" Zero-Turn Mower, 19hp Kawasaki (SN: 000101 & Above) Seat Parts Diagram
Pro-Master 48" Zero-Turn Mower, 19hp Kawasaki
Seat Parts Diagram
Gravely 03829400
Assembly, Seat with Armrests
$448.99
$
In Stock, only 1 left!
$1.99
$
In Stock, Qty 20+
Gravely 05500901
Bushing, Flange .515 x .750 x .745 x 1.00
$6.49
$
Usually ships in 4-12 days
Gravely 02982751
Weldment, Seat Plate
$118.99
$
Usually ships in 4-12 days
Gravely 03255700
Weldment, Seat Shaft
$52.99
$
Usually ships in 4-12 days
Gravely 07000034
Bolt, Shoulder EP .38-16 x .30 Hex
$3.99
$
In Stock, Qty 10
$1.99
$
In Stock, Qty 20+
$2.99
$
In Stock, Qty 20+
Gravely 08300021
Spring, Seat
$21.99
$
Usually ships in 4-12 days
$2.99
$
In Stock, Qty 20+
Gravely 06533500
Nut, Coupling .375-16 x 1.75
$3.99
$
In Stock, Qty 5
Gravely 00337700
Hub Cap
$2.99
$
In Stock, Qty 20+
