991096 (Pro-Turn 152) - Gravely Pro-Turn 52" Zero-Turn Mower, Kohler EFI (SN: 021000 - 029999) Discharge Chute & Belt Covers Parts Diagram

Pro-Turn 52" Zero-Turn Mower, Kohler EFI

Discharge Chute & Belt Covers Parts Diagram

  • Title

1

Gravely 06224100

BLT-RDHDSQNK .38-16X1.25 G5YZ
(Superseded to 06200415)

$2.99

$

In Stock, Qty 20+

0

2

Gravely 07000037

PULL PIN,.50-13THDX.310 PLNGR

$11.99

$

In Stock, Qty 7

0

3

Gravely 05958000

BLT-HEX .38-16X1.25 GR5 YWZC
(Superseded to 05901724)

$1.99

$

In Stock, Qty 20+

0

4

Gravely 06200002

BLT,RDHDSQNK .31-18X.75 LOCTIT
(Superseded to 06200425)

$4.99

$

In Stock, Qty 20+

0

5

Gravely 07000027

NUT, COUPLING .31-18 X 3.00

$29.99

$

In Stock, Qty 17

0

6

Gravely 07001525

NUT-HEAVY HEX .38-16 YWZC
(Superseded to 06500823)

$1.99

$

In Stock, Qty 20+

0

7

Gravely 06534900

NUT-SPNLK-FLG .375-16 YWZC
(Superseded to 06500735)

$1.99

$

In Stock, Qty 20+

0

8

Gravely 03977151

GUARD,LH DECK BELT,44-52

Note: (991079, 080, 095, 096, 102, 103)

$92.99

$

Usually ships in 4-12 days

0

Gravely 03977251

GUARD,LH DECK BELT,60

Note: (991081, 097, 104)

$73.99

$

Usually ships in 4-12 days

0

9

Gravely 04590251

GUARD 48-52 RH DECK BELT-BLACK

Note: (991079, 080, 095, 096, 102, 103)

$58.99

$

In Stock, only 1 left!

0

Gravely 03982251

GUARD,RH DECK BELT,60-66

Note: (991081, 097, 104)

$62.99

$

Usually ships in 4-12 days

0

10

Gravely 06223600

BLT-RDHDSQNK .38-16X1.00 G5YZ
(Superseded to 06200313)

$2.99

$

In Stock, Qty 20+

0

11

Gravely 04551553

RUBBER DISCH CHUTE SUPPORT-RED

$105.99

$

Usually ships in 4-12 days

0

12

Gravely 04551600

CHUTE, RUBBER DISCHARGE

$70.99

$

In Stock, Qty 9

0

13

Gravely 00472453

44"-48" DISCH CHUTE MTG WMT-RD
(Superseded to 04757453)

Note: (991079, 095, 102)

$115.99

$

In Stock, only 4 left!

0

Gravely 00472553

52"-60" DISCH CHUTE MTG WMT-RD
(Superseded to 04727953)

Note: (991080, 081, 096, 097, 103, 104)

$131.99

$

In Stock, only 1 left!

0

14

Gravely 06545500

NUT-LK-NYL-FLG .38-16 YWZC
(Superseded to 06500726)

$1.99

$

In Stock, Qty 20+

0

15

Gravely 05946800

BLT-HEX .25-20X.75 GR5 YWZC
(Superseded to 05901716)

Note: (991079, 095, 102)

$1.49

$

In Stock, only 3 left!

0

16

Gravely 01593500

PIN, SPRING BALL .375OD X 1.50

Note: (991079, 095, 102)

$6.49

$

In Stock, Qty 18

0

17

Gravely 06543500

NUT-LK-TOP-FLG .25-20 YWZC
(Superseded to 06500903)

Note: (991079, 095, 102)

$1.49

$

In Stock, Qty 15

0

18

Gravely 06900321

CABLE, 6.0 LANYARD, NYLON

Note: (991079, 095, 102)

$6.49

$

In Stock, only 2 left!

0

19

Gravely 07533600

BUMPER, RUBBER

$12.99

$

In Stock, Qty 5

0

20

Gravely 07412900

SCR-TAP .38-16X.50 HWH TR YWZ
(Superseded to 07400126)

$1.99

$

In Stock, Qty 20+

0

21

Gravely 04551051

BAFFLE-44"/48" LH VACUUM
(Superseded to 05251651)

Note: (991079, 095, 102)

$21.99

$

Usually ships in 4-12 days

0

Gravely 00952951

52" LH VACUUM BAFFLE - BLK
(Superseded to 05251851)

Note: (991080, 096, 103)

$37.99

$

In Stock, only 1 left!

0

Gravely 00952651

60" LH VACUUM BAFFLE - BLK
(Superseded to 05252051)

Note: (991081, 097, 104)

$44.99

$

Usually ships in 4-12 days

0

22

Gravely 04550951

BAFFLE-48" RH VACUUM
(Superseded to 05251551)

Note: (991079, 095, 102)

$56.99

$

Usually ships in 4-12 days

0

Gravely 00952851

52" RH VACUUM BAFFLE - BLK
(Superseded to 05251751)

Note: (991080, 096, 103)

$44.99

$

Usually ships in 4-12 days

0

Gravely 00952551

60" RH VACUUM BAFFLE - BLK
(Superseded to 05251951)

Note: (991081, 097, 104)

$52.99

$

In Stock, only 1 left!

0

23

Gravely 06215700

BLT-RDHDSQNK .31-18X.75 G5YZ
(Superseded to 06200232)

$2.99

$

In Stock, Qty 20+

0

24

Gravely 06530200

NUT-LK-NYL .312-18 YWZC
(Superseded to 06500820)

$1.49

$

In Stock, Qty 6

0
