991400 (EZKW2352S) - EverRide Hornet 52" Zero-Turn Mower, 23hp Kawasaki (SN: 000101 - 009999) Engine And Exhaust Parts Diagram

Hornet 52" Zero-Turn Mower, 23hp Kawasaki

Engine And Exhaust Parts Diagram

  • Title

1

Gravely 00180273

Cable, Choke 48"

$52.99

$

In Stock, only 1 left!

0

2

Gravely 03551000

Solenoid, 12 V Starter

$34.99

$

In Stock, Qty 6

0

3

Gravely 00180842

Cable, 12’ Starter

$15.99

$

Usually ships in 4-12 days

0

4

Gravely 00181073

Oil Filter
(Superseded to 21535800)

$18.99

$

In Stock, Qty 20+

0

5

Gravely 00200675

Engine, Kawasaki 19 HP (402)

Note: (402)

$

$

Not available

Gravely 00191123

Engine, Kawasaki 23 HP (400)

Note: (400)

$

$

Not available

6

Gravely 00191125

Muffler, Kawasaki ONLY FH-HORI (400)

Note: (400)

$

$

Not available

Gravely 00278200

Muffler, Kawasaki ONLY FH-HORI (402)

Note: (402)

$

$

Not available

7

Gravely 00288200

Adapter Harness, Kawasaki

$

$

Not available

8

Gravely 00191260

Adapter Harness, Kawasaki, Fuse

$

$

Not available

9

Gravely 00191601

Kit, Muffler Gasket (Includes items 9, 11 and 12)

Note: (Includes items 9, 11 and 12)

$54.99

$

Usually ships in 4-12 days

0

10

Gravely AA960000

Bolt, 1/4-20 x .500 Hex 5
(Superseded to 05947900)

$0.99

$

In Stock, Qty 5

0

11

Gravely 00961553

Nut, M8 x 1.25 Hex GR8.8
(Superseded to 06538600)

$1.99

$

Usually ships in 4-12 days

0

12

Gravely 00961603

Washer, M8 Spring Lock
(Superseded to 06318200)

$3.99

$

Usually ships in 4-12 days

0

13

Gravely 00964040

Locknut, 1/4-20 Whiz

$

$

Not available

14

Gravely 00191365

Shield, Exhaust

$

$

Not available

15

Gravely 00181071

Filter, Primary Air (400)

Note: (400)

$59.99

$

In Stock, only 2 left!

0

Gravely 00186700

Filter, Air (402)

Note: (402)

$

$

Not available

16

Gravely 00181072

Filter, Secondary Air (400)

Note: (400)

$56.99

$

Usually ships in 4-12 days

0
