991402 (EZKA1948S) - EverRide Hornet 48" Zero-Turn Mower, 19hp Kawasaki (SN: 000101 - 009999) Brake Linkage Parts Diagram

Hornet 48" Zero-Turn Mower, 19hp Kawasaki

Brake Linkage Parts Diagram

  • Title

1

Gravely 00967393

BOLT, 1/4-20X2.75 SOC 8 Y

$3.99

$

Usually ships in 4-12 days

0

2

Gravely 00150109

CHAIN, 1/4 X 3 LINKS Y

$

$

Not available

3

Gravely 00180922

E-RING, 1.00 X .050 Y
(Superseded to 05700170)

$

$

Not available

4

Gravely 00180956

YOKE, 1/4-20 RH ADJUSTABLE

$

$

Not available

5

Gravely 00180957

SPRING, COM .784X.092X1.50

$

$

Not available

6

Gravely 00180982

BALL JOINT, 5/16 FMAL W/STD

$

$

Not available

7

Gravely 00181017

U-BOLT, RD 1.00X2.50X3/8-16 Y

$18.99

$

Usually ships in 4-12 days

0

8

Gravely 00967353

RING, RUE .375 X .054 X 1.254

$2.99

$

Usually ships in 4-12 days

0

9

Gravely 00191080

ROD, PUMP CONTROL HORNET

$85.99

$

Usually ships in 4-12 days

0

10

Gravely 00255500

PLATE, PUMP CONTROL ARM

$21.99

$

Usually ships in 4-12 days

0

11

Gravely 00967350

RING, RUE .250 X .041 X .844

$

$

Not available

12

Gravely 00967342

LOCKNUT, 7/16-14 WHIZ Y
(Superseded to 06530004)

$2.49

$

Usually ships in 4-12 days

0

13

Gravely 00967338

NUT, 5/16-24 HEX GR5 LH Y
(Superseded to 06547200)

$3.99

$

Usually ships in 4-12 days

0

14

Gravely 00964016

LOCKNUT, 3/8-16 WHIZ Y
(Superseded to 06534900)

$1.99

$

In Stock, Qty 20+

0

15

Gravely 00964003

NUT, 5/16-24 STD HEX GR5 Y

$

$

Not available

16

Gravely 00963074

BOLT, 5/16-18X1.00 CRG 2 Y

$

$

Not available

17

Gravely 00191129

CHAIN, 2 LINKS 1/4" Y

$

$

Not available

18

Gravely 00967054

NUT, 3/8-24 STD HEX Y
(Superseded to 06522900)

$2.99

$

In Stock, only 2 left!

0

19

Gravely 00191175

ROD, BRAKE GEN 1

$

$

Not available

20

Gravely 00191176

PIN, BRAKE LINKAGE

$

$

Not available

21

Gravely 00191177

SPRING, COM .710X.142X2.50

$21.99

$

Usually ships in 4-12 days

0

22

Gravely 00964066

LOCKNUT, 3/8-24 CROWN Y
(Superseded to 06512300)

$3.99

$

Usually ships in 4-12 days

0

23

Gravely 00964061

LOCKNUT, 7/16-14 CENTER Y
(Superseded to 06536400)

$3.49

$

In Stock, only 4 left!

0

24

Gravely 00964048

LOCKNUT, 1/4-20 NYLOC Y

$

$

Not available

25

Gravely 00191227

CABLE, BATTERY - 35" GROUND

$

$

Not available

26

Gravely 00191509

WLDT, WHEEL MOTOR PLATE

$

$

Not available

27

Gravely 03890161

WLDT, LH REAR DECK PIVOT

$

$

Not available

28

Gravely 03891261

WLDT, RH REAR DECK PIVOT

$

$

Not available

29

Gravely 03785761

WLDT, BATTERY/TANK (EVERRIDE)

$

$

Not available

30

Gravely 00964025

LOCKNUT, 7/16-14 CROWN Y
(Superseded to 06508200)

$

$

Not available

31

Gravely 00964022

LOCKNUT, 3/8-16 CROWN Y

$

$

Not available

32

Gravely 00964021

LOCKNUT, 5/16-18 CROWN Y
(Superseded to 06530800)

$6.49

$

Usually ships in 4-12 days

0

33

Gravely 00964019

LOCKNUT, 5/16-18 WHIZ Y
(Superseded to 06530400)

$1.99

$

In Stock, Qty 20+

0

34

Gravely 00473450

BOLT, 1/2-13X2.75 HEX 2 FLTD Y

$

$

Not available

35

Gravely 00960025

BOLT, 5/16-18X1.50 HEX 5 Y

$

$

Not available

36

Gravely 00960026

BOLT, 5/16-18X1.75 HEX 5 Y
(Superseded to 05901804)

$3.49

$

In Stock, Qty 10

0

37

Gravely 00960047

BOLT, 3/8-16X1.25 HEX 5 Y
(Superseded to 05958000)

$1.99

$

In Stock, Qty 20+

0

38

Gravely 00960081

BOLT, 7/16-14X1.50 HEX 5 Y
(Superseded to 05962800)

$3.49

$

In Stock, Qty 6

0

39

Gravely 00960504

NUT, 1/2-13 STD HEX GR5 Y
(Superseded to 06537300)

$4.99

$

Usually ships in 4-12 days

0

40

Gravely AA960601

WASHER, .313 MED SPRG LOCK Y
(Superseded to 06308600)

$1.49

$

In Stock, Qty 20+

0

41

Gravely AA960700

WASHER, .250 REG FLAT Y
(Superseded to 06435800)

$1.49

$

In Stock, Qty 20+

0

42

Gravely 00960701

WASHER, .313 REG FLAT Y
(Superseded to 06401023)

$1.99

$

In Stock, Qty 20+

0

43

Gravely 00960702

WASHER, .375 REG FLAT Y
(Superseded to 06435900)

$1.99

$

In Stock, Qty 20+

0

44

Gravely AA962200

PIN, CVS .250X1.00X.859 Y
(Superseded to 06818500)

$3.99

$

Usually ships in 4-12 days

0

45

Gravely 00961284

BOLT, M8X1.25X20 HEX 8.8 Y

$1.99

$

Usually ships in 4-12 days

0
