992001 (Pro-Vac 1050) - Gravely Pro-Vac Vacuum, 18hp Kohler Command (SN: 000101 & Above) FRAME AND WHEELS Parts Diagram

Pro-Vac Vacuum, 18hp Kohler Command

FRAME AND WHEELS Parts Diagram

  • Title

1

Gravely 04200100

Frame Weldment

$

$

Not available

2

Gravely 09200100

Hitch Pin 1 Inch
(Superseded to 02087300)

$

$

Not available

3

Gravely 06442900

Wshr-Fl-Stl .688 x 1.75 x .134
(Superseded to 06401032)

$1.49

$

In Stock, only 2 left!

0

4

Gravely 04963900

Blt-Hex .62 - 11 x 3.00 Pl Gr 5

$

$

Not available

5

Gravely 04200251

Tongue Weldment

$

$

Not available

6

Gravely 06535300

Nut-Lk-Ctr .62-11

$2.99

$

In Stock, only 1 left!

0

7

Gravely 04201300

Jack

$

$

Not available

8

Gravely 04207700

Dust Cap

$

$

Not available

9

Gravely 59200200

Kit, Wheel Nut

$

$

Not available

10

Gravely 59200100

Kit, Hub Complete 1050 Vac

$

$

Not available

11

Gravely 07136200

Tire & Wheel Assembly

$

$

Not available

12

Gravely 04201400

Hub Assembly

$

$

Not available

13

Gravely 05717900

Ring-Retaining-External 2.500 x .078

$

$

Not available

14

Gravely 06712600

Pin-Cotter .12 x 1.25
(Superseded to 06700212)

$0.99

$

In Stock, Qty 8

0

15

Gravely 06517600

Wheel Nut .50-20
(Superseded to 06500926)

$1.49

$

In Stock, Qty 20+

0

16

Gravely 06427900

Washer-Flat-Steel 2.0 x 1.12 x .148

$5.99

$

Usually ships in 4-12 days

0
