992143 (ZT 2348 XL) - Gravely 48" Zero-Turn Mower, 23hp Kohler (SN: 000101 - 001999) Anti-Scalp Rollers Parts Diagram

48" Zero-Turn Mower, 23hp Kohler

Anti-Scalp Rollers Parts Diagram

  • Title

1

Gravely 03471700

Wheel, 5 x 3
(Superseded to 03905600)

$17.99

$

In Stock, Qty 20+

0

2

Gravely 06545500

Nut, .38-16 Flange Nyloc
(Superseded to 06500726)

$1.99

$

In Stock, Qty 20+

0

3

Gravely 01574851

Bracket, Anti Scalp
(Superseded to 02950351)

$30.99

$

In Stock, only 2 left!

0

4

Gravely 07056800

Bolt, Shoulder .38-16 x 2.50 Hex Washer Head Grade 5

$7.49

$

In Stock, Qty 20+

0

5

Gravely 06223600

Bolt, Round Head Square Neck .38-16 x 1.00 Grade 5
(Superseded to 06200313)

$2.99

$

In Stock, only 3 left!

0

6

Gravely 06714500

Pin, Spring Clip

$2.99

$

In Stock, Qty 19

0

7

Gravely 00355651

Bracket, Roller Mount

$63.99

$

In Stock, only 3 left!

0

8

Gravely 03114100

Roller

$23.99

$

In Stock, Qty 10

0

9

Gravely 00356500

Pin, Roller

$35.99

$

In Stock, only 2 left!

0
