992236 (Pro-Turn 460) - Gravely Pro-Turn 60" Zero-Turn Mower, Kubota Diesel (SN: 040000 - 049999) Radiator Frame Parts Diagram

Pro-Turn 60" Zero-Turn Mower, Kubota Diesel

Radiator Frame Parts Diagram

  • Title

1

Gravely 04439051

GUARD, OPERATOR PT400 DIESEL

Note: BLACK

$131.99

$

Usually ships in 4-12 days

0

2

Gravely 04505353

SUPPORT, DIESEL HOOD FRONT

Note: (RED)

$

$

Not available

3

Gravely 04508700

STRT, GAS

$50.99

$

Usually ships in 4-12 days

0

4

Gravely 04513151

BRKT, SIGNAL MOUNT - BLACK

$

$

Not available

5

Gravely 04729051

WLDMT, DIESEL RADIATOR ISO CHANNEL

Note: BLACK

$

$

Not available

6

Gravely 04734351

WLDMT, RADIATOR / HOOD SUPPORT REAR

Note: (BLACK)

$263.99

$

Usually ships in 4-12 days

0

7

Gravely 04738351

WLDMT, RADIATOR /HOOD MOUNT

Note: (BLACK)

$435.99

$

Usually ships in 4-12 days

0

8

Gravely 05946800

BLT-HEX .25-20X.75 GR5 YWZC
(Superseded to 05901716)

$1.49

$

In Stock, Qty 12

0

9

Gravely 05946900

BLT-HEX .31-18X1.00 GR5 YWZC
(Superseded to 05901701)

$1.99

$

In Stock, Qty 10

0

10

Gravely 05947700

BLT-HEX .25-20X1.00 GR5 YWZC
(Superseded to 05901639)

$1.99

$

In Stock, Qty 8

0

11

Gravely 05948000

BLT-HEX .31-18X3.50 GR5 YWZC

$2.99

$

Usually ships in 4-12 days

0

12

Gravely 05959400

BLT-HEX .38-16X.75 GR5 YWZC
(Superseded to 05901702)

$1.99

$

In Stock, Qty 10

0

13

Gravely 06200214

BLT, RDHDSQNK .25-20 X .625 YWZC RED HEAD

$3.99

$

Usually ships in 4-12 days

0

14

Gravely 06433600

WSHR-FL-NYL .375X.75X.060

$0.99

$

In Stock, Qty 9

0

15

Gravely 06436200

WSHR-FL-STL.406X.812X.065 YWZ
(Superseded to 06401013)

$1.49

$

In Stock, Qty 20+

0

16

Gravely 06437200

WSHR-FL-STL.344X.688X.065YWZC
(Superseded to 06401017)

$0.99

$

In Stock, Qty 20+

0

17

Gravely 06437300

WSHR-FL-STL.281X.62X.065 YWZC
(Superseded to 06401001)

$0.99

$

In Stock, only 3 left!

0

18

Gravely 06500012

NUT-LK-NYL-FLG .25-20 YWZC
(Superseded to 06500813)

$1.99

$

In Stock, Qty 6

0

19

Gravely 06529800

NUT-LK-CTR .31-18 YWZC
(Superseded to 06500826)

$1.99

$

In Stock, Qty 20+

0

20

Gravely 06530400

@NUT-SPNLK-FLG .312-18 YWZC
(Superseded to 06500815)

$1.99

$

In Stock, Qty 20+

0

21

Gravely 06545400

NUT-LK-NYL-FLG .31-18 YWZC
(Superseded to 06500809)

$1.99

$

In Stock, Qty 20+

0

22

Gravely 07411500

SCR-TAP .31-18X.50 HWH TR YWZ
(Superseded to 07400124)

$1.99

$

In Stock, Qty 20+

0

23

Gravely 07500312

BUMPER, RUBBER, 3/8" SILICON

$21.99

$

Usually ships in 4-12 days

0
