992327 (Pro-Turn 272) - Gravely Pro-Turn 72" Zero-Turn Mower, Kawasaki FX (SN: 030000 - 039999) Frame Parts Diagram

Pro-Turn 72" Zero-Turn Mower, Kawasaki FX

Frame Parts Diagram

  • Title

1

Gravely 03948151

MUFFLER HEAT SHIELD - BLACK

$77.99

$

Usually ships in 4-12 days

0

2

Gravely 03948251

BUMPER BACKER PLATE - BLACK

$19.99

$

Usually ships in 4-12 days

0

3

Gravely 03985600

BSHG-SLV .50X.75X2.23

$10.99

$

Usually ships in 4-12 days

0

4

Gravely 04386551

BUMPER LOGO BACKING PLATE -BLK

$11.99

$

Usually ships in 4-12 days

0

5

Gravely 04524553

PLATE-TRANSMISSION SKID

$85.99

$

Usually ships in 4-12 days

0

6

Gravely 05500924

BSHG-FLG .75X1.51X1.13X2.0 URE

$12.99

$

Usually ships in 4-12 days

0

7

Gravely 05958900

@BLT-HEX .50-13X1.25 GR5 YWZC
(Superseded to 05901637)

$3.99

$

In Stock, only 2 left!

0

8

Gravely 05962900

@BLT-HEX .38-16X2.25 GR5 YWZC
(Superseded to 05901640)

$5.49

$

In Stock, Qty 20+

0

9

Gravely 05965800

@BLT-HEX .50-13X3.50 GR5 YWZC
(Superseded to 05901937)

$5.99

$

In Stock, only 3 left!

0

10

Gravely 06222000

@BLT-RDHDSQNK .31-18X.50 G5YZ
(Superseded to 06200406)

$3.99

$

In Stock, Qty 14

0

11

Gravely 06307300

@WSHR-LK .50X.125 REG YWZC
(Superseded to 06300115)

$1.99

$

In Stock, Qty 20+

0

12

Gravely 06436200

@WSHR-FL-STL.406X.812X.065 YWZ
(Superseded to 06401013)

$2.49

$

In Stock, Qty 20+

0

13

Gravely 06442000

@WSHR-FL-STL.563X1.38X.109YWZC
(Superseded to 06401012)

$3.49

$

In Stock, Qty 20+

0

14

Gravely 06500010

@NUT-LK-NYL-FLG .50-13 YWZC
(Superseded to 06500810)

$2.99

$

In Stock, Qty 20+

0

15

Gravely 06530400

@NUT-SPNLK-FLG .312-18 YWZC
(Superseded to 06500815)

$2.49

$

In Stock, Qty 20+

0

16

Gravely 03855553

PT200/400 AXLE/ENG FRM WMT-RED

$647.99

$

Usually ships in 4-12 days

0

17

Gravely 59217900

72" PT272/400 FRAME W/DECALS

$1792.99

$

Usually ships in 4-12 days

0

18

Gravely 59220100

FOOTPLATE WLDMT W/SAFETY DECAL

$182.99

$

Usually ships in 4-12 days

0

19

Gravely 06545500

@NUT-LK-NYL-FLG .38-16 YWZC
(Superseded to 06500726)

$2.49

$

In Stock, Qty 20+

0

20

Gravely 07000034

BLT,SHLDR EP .38-16X.30 HEX YZ

$4.99

$

In Stock, Qty 17

0

21

Gravely 07400034

SCR-TAP .25-20X.50 HWH TR YWZ
(Superseded to 07400122)

$1.49

$

In Stock, Qty 20+

0

22

Gravely 07500214

BUMPER,STUD MNTD W/FEMALE INSR

$21.99

$

In Stock, Qty 13

0

23

Gravely 07533600

BUMPER, RUBBER

$13.99

$

In Stock, only 2 left!

0

24

Gravely 59220000

INSPECTION PANEL W/SAFTY DECAL

$60.99

$

Usually ships in 4-12 days

0

25

Gravely 59218000

PRO-TURN 200 BUMPER W/DECALS

$262.99

$

Usually ships in 4-12 days

0
