994119 - Gravely Pro-Stance 36" Stand-On Mower, Kawasaki FS (SN: 000101 - 039999) Deck Lift - Right Arm Parts Diagram

Pro-Stance 36" Stand-On Mower, Kawasaki FS

Deck Lift - Right Arm Parts Diagram

  • Title

1

Gravely 00442800

BRKT, DECK LEVELING

$9.49

$

In Stock, only 1 left!

0

3

Gravely 03929100

GRIP, HANDLEBAR

$15.99

$

In Stock, only 2 left!

0

4

Gravely 04732500

LINK, DECK LIFT - SHORT

$9.99

$

Usually ships in 4-12 days

0

5

Gravely 04681651

LINK, DECK LIFT HANDLE

$21.99

$

Usually ships in 4-12 days

0

6

Gravely 05500934

BSHG-FLG 1.00X1.25X1.5X1.5

$6.99

$

In Stock, Qty 20+

0

7

Gravely 05501117

BSHG, 1.00 X 1.25 X .75

$17.99

$

Usually ships in 4-12 days

0

8

Gravely 05501135

BSHG, FLANGE .515X.750X.420X1.12

$15.99

$

In Stock, only 1 left!

0

10

Gravely 04635551

PLATE, DECK ARM

$22.99

$

Usually ships in 4-12 days

0

11

Gravely 05959400

BLT-HEX .38-16X.75 GR5 YWZC
(Superseded to 05901702)

$1.49

$

In Stock, only 1 left!

0

14

Gravely 05962000

BLT-HEX .50-13X1.50 GR5 YWZC
(Superseded to 05901631)

$3.99

$

In Stock, only 1 left!

0

15

Gravely 05980900

BLT-HEX .31-18X2.00 FTH GR5 YWZC
(Superseded to 05902003)

$2.99

$

In Stock, only 1 left!

0

16

Gravely 04695467

WLDMT, RH FRONT DECK ARM (BLACK)

Note: (BLACK)

$84.99

$

Usually ships in 4-12 days

0

17

Gravely 04662251

WLDMT, REAR DECK ARM

$49.99

$

Usually ships in 4-12 days

0

18

Gravely 05959700

BLT-HEX .50-13X2.00 GR5 YWZC
(Superseded to 05901929)

$3.49

$

Usually ships in 4-12 days

0

19

Gravely 04681553

WLDMT, DECK LIFT HANDLE

$131.99

$

Usually ships in 4-12 days

0

20

Gravely 06536100

NUT, JAM .312-18 YWZC
(Superseded to 06500909)

$0.99

$

In Stock, only 3 left!

0

21

Gravely 06500010

NUT-LK-NYL-FLG .50-13 YWZC
(Superseded to 06500810)

$2.49

$

In Stock, Qty 20+

0

22

Gravely 06543300

NUT .50-13 WIZ FLANGE
(Superseded to 06500928)

$3.99

$

Usually ships in 4-12 days

0

23

Gravely 06443400

WSHR-FL-STL .380X1.50X.125 YWZC
(Superseded to 06401106)

$3.49

$

In Stock, Qty 20+

0

24

Gravely 06441900

WSHR-FL-STL.531X1.06X.095YWZC
(Superseded to 06401015)

$0.99

$

In Stock, Qty 20+

0

25

Gravely 06442000

WSHR-FL-STL.563X1.38X.109YWZC
(Superseded to 06401012)

$3.49

$

In Stock, Qty 17

0

31

Gravely 05962000

BLT-HEX .50-13X1.50 GR5 YWZC
(Superseded to 05901631)

$3.99

$

In Stock, only 1 left!

0
