994401 (EFZKA1934S) - Ariens Scorpion 34" Stand-On Mower, 19hp Kawasaki (SN: 000101 & Above) Foot Plate Parts Diagram

Scorpion 34" Stand-On Mower, 19hp Kawasaki

Foot Plate Parts Diagram

  • Title

1

Ariens 00200619

PLATE, PLATFORM TAB

$

$

Not available

2

Ariens 00200655

BUMPER, MINER GBR-6

$

$

Not available

3

Ariens 00200693

PLATE, PLATFORM TAB LH

$

$

Not available

4

Ariens 00200767

ANCHOR, OPC

$

$

Not available

5

Ariens 00201136

PLATFORM

$

$

Not available

6

Ariens 00960001

BOLT, 1/4-20X.750 HEX 5 Y

$

$

Not available

7

Ariens 00960701

WASHER, .313 REG FLAT Y
(Superseded to 06401023)

$1.49

$

In Stock, Qty 14

0

8

Ariens 00963019

BOLT, 3/8-16X1.00 CRG 5 SN Y

$

$

Not available

9

Ariens 00963074

BOLT, 5/16-18X1.00 CRG 2 Y

$

$

Not available

10

Ariens 00964048

LOCKNUT, 1/4-20 NYLOC Y

$

$

Not available

11

Ariens 00967115

LOCKNUT, 5/16-18 NYLOC Y
(Superseded to 06500820)

$0.99

$

Usually ships in 4-12 days

0

12

Ariens 00968087

LOCKNUT, 3/8-16 NYLOC Y

$

$

Not available
