994401 (EFZKA1934S) - EverRide Pro Walk-Behind Mower (SN: 000101 & Above) Deck Parts Diagram

Pro Walk-Behind Mower

Deck Parts Diagram

  • Title

1

Gravely D13024

SPACER, 1.500X1.000X.510 Y

$14.99

$

In Stock, only 2 left!

0

2

Gravely D18032

PULLEY, FLAT 5.0X.38 W/BRG
(Superseded to 07346700)

$82.99

$

In Stock, Qty 6

0

3

Gravely D18055

WASHER, BLADE
(Superseded to 06401033)

$7.49

$

In Stock, only 4 left!

0

4

Gravely D18076

BRG, FLG 1.00X1.25X1.00

$7.49

$

In Stock, only 3 left!

0

5

Gravely D18084

PULLEY, SPLINE SPINDLE OFFSET
(Superseded to 07329667)

$98.99

$

In Stock, only 2 left!

0

6

Gravely D18209

PULLEY, V-BELT 5.27X.990 W/SPL

$93.99

$

Usually ships in 4-12 days

0

7

Gravely D24019

WASHER, .402X2.00X.055 FEND Y

$

$

Not available

8

Gravely D23058

J-BOLT, 3/8-16 X 4.00 Y

$6.49

$

Usually ships in 4-12 days

0

9

Gravely GDA10103

PIVOT, RETAINER WELD

$56.99

$

In Stock, Qty 7

0

10

Gravely GDU10230

BLADE, 16.50 LO-LIFT

$29.99

$

In Stock, Qty 10

0

11

Gravely GDU10231

BLADE, 18"

$31.99

$

In Stock, Qty 20+

0

12

Gravely H122207

NUT-1/4" FLANGE PREVAILING TOR

$

$

Not available

13

Gravely H141123

RETAINER #

$

$

Not available

14

Gravely M132768

SPRING,CHUTE GUARD

$9.99

$

In Stock, only 1 left!

0

15

Gravely M119352

KNOB, LOCKING

$3.99

$

In Stock, only 4 left!

0

16

Gravely N242189

SPRING, TENSION

$10.99

$

Usually ships in 4-12 days

0

17

Gravely TCA16387

CHUTE DISCHARGE ASST #

$37.99

$

In Stock, only 2 left!

0

18

Gravely TCU18744

WHEEL, GAGE

$14.99

$

In Stock, only 4 left!

0

19

200260

ASSY, SPINDLE HOUSING

$

$

Not available

20

201010

BELT, HB 80.3 EL AMD OHR

$

$

Not available

21

201145

WLDT, IDLER ARM

$

$

Not available

22

Gravely 03729403

WLDT, 34" DECK

$

$

Not available

23

Gravely 03733003

ASSY, FR WHEEL CASTER

$

$

Not available

24

297511

SHIELD, DECK 34

$

$

Not available

25

201178

WLDT, IDLER PIVOT

$

$

Not available

26

424390

SNAP RING, 1.00 X .042 EXT

$

$

Not available

27

959995

FTG, 1/4-28 STRGT GREASE ZERK

$

$

Not available

28

960046

BOLT, 3/8-16 X 1.00 HEX 5 Y

$

$

Not available

29

960051

BOLT, 3/8-16 X 2.25 HEX 5 Y

$

$

Not available

30

960502

NUT, 3/8-16 STD HEX GR5 Y

$

$

Not available

31

963019

BOLT, 3/8-16 X 1.00 CRG 5 SN Y

$

$

Not available

32

963095

BOLT, 1/4-20 X .750 CRG 5 Y

$

$

Not available

33

964016

LOCKNUT, 3/8-16 WHIZ Y

$

$

Not available

34

964022

LOCKNUT, 3/8-16 CROWN Y

$

$

Not available

35

964501

WASHER, .406 X .813 X .065 FLAT Y

$

$

Not available

36

964024

LOCKNUT, 3/4-16 CROWN Y

$

$

Not available

37

967348

BOLT, 5/8-11 X 2.00 HEX 8 Y

$

$

Not available

38

968087

LOCKNUT, 3/8-16 NYLOC Y

$

$

Not available

39

999538

TRIM 1/4

$

$

Not available
