995420 (Pro-Vac 1060) - Gravely Pro-Vac Vacuum, 18hp Kohler Command (SN: 000101 - 002499) Hopper Parts Diagram

Pro-Vac Vacuum, 18hp Kohler Command

Hopper Parts Diagram

  • Title

1

Gravely 02084151

Weldment, Grid

$

$

Not available

2

Gravely 02084551

Link Spacer, Screen Door

$

$

Not available

3

Gravely 02085053

Weldment, Screen Door

$

$

Not available

4

Gravely 06400509

Washer, Flat .312
(Superseded to 06401017)

$0.99

$

In Stock, Qty 16

0

5

Gravely 02084000

Quick Link .25

$

$

Not available

6

Gravely 06500522

Nut, Hex Lock .312-18

$1.99

$

In Stock, only 1 left!

0

7

Gravely 02078853

Weldment, Hopper

$1106.99

$

Usually ships in 4-12 days

0

8

Gravely 02952900

Screen, Single (995420, 430)

Note: (995420, 430)

$

$

Not available

Gravely 02141900

Screen / Filter, Hard Surface (995430)

Note: (995430)

$

$

Not available

9

Gravely 05900738

Cap Screw, Hex Head .312-18 x 1.50

$

$

Not available

10

Gravely 02084851

Linkage, Filter Door

$

$

Not available

11

Gravely 02221600

Cap Screw, Flat Countersunk Head Hex Socket .312-18 x 1.00

$3.99

$

In Stock, only 1 left!

0

12

Gravely 02084651

Latch, Filter Door Right Hand

$

$

Not available

Gravely 02084751

Latch, Filter Door Left Hand

$

$

Not available

13

Gravely 02072000

Gasket Material .75 x .25

$

$

Not available

14

Gravely 06700118

Pin, Cotter Stainless Steel .125 x .75

$

$

Not available

15

Gravely 02952400

Pin, Clevis .38 x 1.125

$

$

Not available

16

Gravely 08300351

Spring

$

$

Not available

17

Gravely 02081853

Weldment, Door

$

$

Not available

18

Gravely 05900801

Cap Screw, Hex Head .38-16 x 1.00
(Superseded to 05901711)

$1.99

$

In Stock, Qty 17

0

19

Gravely 06400417

Washer, Flat .38

$

$

Not available

20

Gravely 02083951

Brace, Hopper

$

$

Not available

21

Gravely 02144300

Nut, Lock .38-16

$

$

Not available

22

Gravely 06200107

Bolt, Carriage .50-13 x 1.50

$

$

Not available

23

Gravely 06400416

Washer, Flat .50

$

$

Not available

24

Gravely 02116500

Nut, Lock .50-13

$

$

Not available

25

Gravely 05901107

Cap Screw, Hex Head .38 x .75

$

$

Not available
