AGR 1300 H - Billy Goat Landscape Auger General Assembly 9 Parts Diagram

Landscape Auger

General Assembly 9 Parts Diagram

  • Title

9

Billy Goat 8165002

NUT-HEX-NYLK, FLG .3125-18 ZP

$0.99

$

In Stock, Qty 7

0

10

Billy Goat 8165003

NUT-HEX-NYLK, FLG .375"-16 ZP

$0.99

$

In Stock, only 2 left!

0

17

Billy Goat 540262

BALL STUD, 1/2" X 5/16-18 ZP

$11.99

$

Usually ships in 2-11 days

0

76

Billy Goat 501217

BUSHING 1.500 ID X 1.5 LONG FLANGED

$

$

Not available

77

Billy Goat 501214

WASHER DECK RETAINING

$13.99

$

Usually ships in 2-11 days

0

78

Billy Goat 8177012

WASHER LOCK 3/8" S/T MED

$0.99

$

In Stock, Qty 7

0

79

Billy Goat 900154

SCREWCAP 3/8"-24 X 1" HCS GR 8

$2.49

$

Usually ships in 2-11 days

0

87

Billy Goat 500334

ENGINE 13HP HONDA GX390UTQA2

$

$

Currently unavailable

89

Billy Goat 540104

WA, TANK, HYDRAULIC, 3 GAL

$

$

Currently unavailable

117

Billy Goat 540213

PULLEY, 4.00"

$180.99

$

Usually ships in 2-11 days

0

122

Billy Goat 8181013

WSHR-STL,BLV, .450"X1.500"X.172" MZ

$

$

Currently unavailable

123

Billy Goat 373305

HOURMETER, INDUCTIVE PANEL MOUNT

$88.99

$

Usually ships in 2-11 days

0

133

Billy Goat 540338

SHIELD, TRANSAXLE

$

$

Currently unavailable

138

Billy Goat 351264

SER HEX WASHER FLNG SCREW 5/16"-18 X 3/4"

$0.99

$

In Stock, Qty 6

0

145

Billy Goat 9201113

KEY SQUARE 1/4" X 1"

$2.99

$

In Stock, only 2 left!

0

156

Billy Goat 890456

LABEL DECAL SM CIRCLE

$5.99

$

In Stock, only 1 left!

0

164

Billy Goat 5103184

DECAL, WARNING, HAND IN BELT, ENG. ONLY

$14.99

$

Usually ships in 2-11 days

0

174

Billy Goat 831273

SCREWCAP 7/16-20 X 1 1/2 GR 8 W/PATCH

$

$

Not available
