AH 230 - Shindaiwa Articulating Hedge Trimmer Fan Cover Parts Diagram

Articulating Hedge Trimmer

Fan Cover Parts Diagram

  • Title

1

Echo 70135-31470

CAP
(Superseded to A575000460)

$9.49

$

Usually ships in 2-4 days

0

2

Echo 11022-05160

SCREW - 5X16
(Superseded to V203000590)

$1.49

$

In Stock, Qty 6

0

3

Echo 20018-31420

CUSHION - FRONT
(Superseded to V420002640)

$4.49

$

Usually ships in 2-4 days

0

4

Echo 11023-05250

SCREW - 5X25
(Superseded to V203000560)

$1.99

$

In Stock, only 3 left!

0

5

Echo 20018-31410

CLAMP, MAIN PIPE
(Superseded to 20018-31411)

$22.99

$

In Stock, only 2 left!

0

6

Echo 20018-31460

SHIM
(Superseded to V340000240)

$

$

Not available

7

Echo 20018-31430

CUSHION - REAR
(Superseded to V420002650)

$5.49

$

In Stock, only 2 left!

0

8

Echo 11022-05160

SCREW - 5X16
(Superseded to V203000590)

$1.49

$

In Stock, Qty 6

0

9

Echo 11022-05350

SCREW - 5X35
(Superseded to V203000600)

$1.99

$

In Stock, Qty 17

0

70140-31103

Echo 70140-31103

FAN CASE ASSY
(Superseded to P021030350)

$146.99

$

Usually ships in 2-4 days

0

10

Echo 70140-31113

CASE, FAN
(Superseded to A172001370)

$41.99

$

Usually ships in 2-4 days

0

11

Echo 20087-31210

DRUM, CLUTCH
(Superseded to 20087-31211)

$25.99

$

In Stock, only 2 left!

0

12

Echo 02002-06000

BEARING, BALL - 6000
(Superseded to 90080406000)

$11.99

$

In Stock, Qty 5

0

13

Echo 02432-26120

RING, RETAINING - 26
(Superseded to 9242426000)

$1.49

$

In Stock, Qty 5

0

14

Echo 70140-31130

CUSHION
(Superseded to V420002620)

$2.49

$

Usually ships in 2-4 days

0

15

Echo 22000-13320

RING, RETAINING
(Superseded to V583000160)

$1.49

$

In Stock, Qty 20+

0

70140-32104

Echo 70140-32104

ENGINE COVER KIT - RED
(Superseded to P021030360)

$

$

Not available

16

Echo 20018-31251

THUMBSCREW
(Superseded to V299000420)

$4.49

$

In Stock, only 1 left!

0

17

Echo 62840-91010

LABEL
(Superseded to X504003220)

$1.99

$

Usually ships in 2-4 days

0

18

Echo 70140-32111

COVER, ENGINE
(Superseded to A160001840)

$14.99

$

In Stock, only 1 left!

0

19

Echo 20018-31260

INSULATOR
(Superseded to V353000430)

$1.99

$

In Stock, only 4 left!

0

20

Echo 20018-31270

CLIP
(Superseded to V490000680)

$1.49

$

In Stock, only 4 left!

0

21

Echo 20024-81790

WASHER - CONICAL
(Superseded to V347000030)

$1.49

$

In Stock, Qty 15

0
