BC 720 (41AJBC-C954) - Troy-Bilt Trimmer Plus Brush Cutter Attachment General Assembly Parts Diagram

Trimmer Plus Brush Cutter Attachment

General Assembly Parts Diagram

  • Title

1

Troy-Bilt 791-180804

Lower Drive Shaft Housing Assembly

$

$

Not available

2

Troy-Bilt 791-613300

Lower Flexible Drive Shaft

$82.99

$

Usually ships in 3-6 days

0

3

Troy-Bilt 791-182200

Shield Mount Screw Assembly

$6.49

$

In Stock, only 2 left!

0

4

Troy-Bilt 791-182193

2 Piece Gearbox Assembly

Note: (Incl Ref # 5-6)

$92.99

$

In Stock, only 2 left!

0

5

Troy-Bilt 791-182195

Gearbox Mounting Hardware

$6.99

$

In Stock, Qty 15

0

6

Troy-Bilt 791-145569

Anti-Rotation Screw

$9.49

$

In Stock, Qty 11

0

7

Troy-Bilt 791-182196

Blade Driver

$20.99

$

In Stock, only 3 left!

0

8

Troy-Bilt 753-04348

Palnut

$6.49

$

In Stock, only 1 left!

0

9

Troy-Bilt 791-147492

Blade Shield/Shield Mount

$118.99

$

Usually ships in 3-6 days

0

10

Troy-Bilt 791-145873

4-Tooth Blade
(Superseded to 791-145873B)

$42.99

$

In Stock, Qty 9

0

11

Troy-Bilt 791-147490

Retaining Washer

$10.99

$

In Stock, Qty 7

0

12

Troy-Bilt 791-181699

Nut
(Superseded to 712-04105)

$9.99

$

In Stock, only 3 left!

0

13

MTD 791-181099

J-Handle Assembly

$

$

Not available

14

Troy-Bilt 791-683295

Handle Bracket Assembly

Note: (Incl Ref # 13-18)

$42.99

$

Usually ships in 3-6 days

0

15

Troy-Bilt 791-181811

Screw

$4.49

$

Usually ships in 3-6 days

0

16

MTD 791-181802

Upper Handle Clamp

$

$

Not available

17

Troy-Bilt 791-181813

Middle Handle Clamp

$11.99

$

Usually ships in 3-6 days

0

18

Troy-Bilt 791-181814

Lower Handle Clamp

$8.49

$

Usually ships in 3-6 days

0

19

Troy-Bilt 791-181815

Nut

$3.99

$

Usually ships in 3-6 days

0

Troy-Bilt 791-180014B

Blade Retaining Kit

Note: (Incl Ref # 11 & 12) (Not Shown)

$12.99

$

In Stock, only 1 left!

0

Troy-Bilt 791-613226

Locking Rod Tool

Note: (Not Shown)

$13.99

$

Usually ships in 3-6 days

0

Troy-Bilt 791-682075B

Shoulder Harness

Note: (Not Shown)

$36.99

$

Usually ships in 3-6 days

0

Troy-Bilt 791-180194

Clamp Shoulder Strap

Note: (Not Shown)

$

$

Not available

Troy-Bilt 791-612605

Hanger
(Superseded to 731-08926)

Note: (Not Shown)

$2.49

$

In Stock, Qty 16

0
