BF130 AY LCA (BZBH) - Honda Marine Engine, Made in Japan (SN: BZBH-1100001 - BZBH-1199999) STARTER CABLE Parts Diagram

Marine Engine, Made in Japan

STARTER CABLE Parts Diagram

  • Title

1

Honda 32185-ZW5-000

WIRE ASSY., INDICATOR

$70.99

$

Usually ships in 3-6 days

0

2

Honda 32410-ZW5-000

CABLE ASSY., STARTER

$

$

Not available

3

Honda 32411-ZW5-003

COVER, STARTER TERMINAL

$13.99

$

Usually ships in 3-6 days

0

4

Honda 32415-425-000

COVER A, MAGNETIC SWITCH

$4.99

$

Usually ships in 3-6 days

0

5

Honda 38201-ZW5-003

FUSE (90A)

$17.99

$

Usually ships in 3-6 days

0

6

Honda 38210-ZW5-003

BOX ASSY., FUSE (90A)

$

$

Not available

7

Honda 38550-ZW5-003

RELAY ASSY., POWER TILT

$467.99

$

Usually ships in 3-6 days

0

8

Honda 38551-ZW1-000

GROMMET, RELAY

$10.99

$

Usually ships in 3-6 days

0

9

Honda 38552-ZW5-000

SEE PART DETAILS - SUP; BRACKET, RELAY
(Superseded to 38552-ZW5-010)

$63.99

$

Usually ships in 3-6 days

0

9

Honda 38552-ZW5-010

SEE PART DETAILS - PRI; BRACKET, RELAY

$63.99

$

Usually ships in 3-6 days

0

10

Honda 38553-ZW5-000

INSULATOR, RELAY

$9.99

$

Usually ships in 3-6 days

0

11

Honda 06380-ZW5-000

SEE PART DETAILS - PRI; RELAY ASSY., MAIN

$75.99

$

Usually ships in 3-6 days

0

11

Honda 06380-ZW5-303

SEE PART DETAILS - SUP; RELAY ASSY., MAIN
(Superseded to 06380-ZW5-000)

$75.99

$

Usually ships in 3-6 days

0

11

Honda 38580-ZW5-004

SEE PART DETAILS - SUP; RELAY ASSY., MAIN
(Superseded to 06380-ZW5-000)

$75.99

$

Usually ships in 3-6 days

0

12

Honda 40105-ZW5-000

GROMMET, CASE (LOWER) (A)

$9.49

$

Usually ships in 3-6 days

0

13

Honda 64417-298-810

GROMMET A, LEG SHIELD

$5.49

$

Usually ships in 3-6 days

0

14

Honda 90013-ZV0-000

BOLT, FLANGE (6X12)
(Superseded to 90013-ZV0-010)

$2.99

$

Usually ships in 3-6 days

0

15

Honda 90106-ZW5-000

BOLT-WASHER (5X9)

$3.49

$

Usually ships in 3-6 days

0

16

Honda 90121-ZV0-000

SEE PART DETAILS - SUP; BOLT, FLANGE (6X25)
(Superseded to 90121-ZV0-010)

$3.99

$

In Stock, only 2 left!

0

16

Honda 90121-ZV0-010

SEE PART DETAILS - PRI; BOLT, FLANGE (6X25)

$3.99

$

In Stock, only 2 left!

0

17

Honda 90153-SB2-003

SCREW-WASHER (5X10)

$7.99

$

Usually ships in 3-6 days

0

18

Honda 90203-ZV5-000

NUT, HEX. (6MM)

$2.49

$

Usually ships in 3-6 days

0

19

Honda 90203-ZW1-000

NUT-WASHER (8MM)

$3.99

$

Usually ships in 3-6 days

0

20

Honda 90630-ZW1-003

CLIP, PURSE LOCK

$3.99

$

Usually ships in 3-6 days

0

21

Honda 91553-ZV5-000

SEE PART DETAILS - SUP; COLLAR, MODULE IGNITION CONTROL CASE (CDI)
(Superseded to 91553-ZV5-010)

$4.49

$

Usually ships in 3-6 days

0

21

Honda 91553-ZV5-010

SEE PART DETAILS - PRI; COLLAR, MODULE IGNITION CONTROL CASE (CDI)

$4.49

$

Usually ships in 3-6 days

0

22

Honda 91558-SD5-003

CLIP, WIRE HARNESS (BLACK)

$13.99

$

Usually ships in 3-6 days

0

23

Honda 94103-06200

WASHER, PLAIN (6MM)

$1.99

$

Usually ships in 3-6 days

0

24

Honda 95701-08018-02

BOLT, FLANGE (8X18)

$2.49

$

Usually ships in 3-6 days

0

25

Honda 98200-31000

FUSE, BLADE (10A)

$1.99

$

Usually ships in 3-6 days

0

26

Honda 98200-33000

FUSE, BLADE (30A)

$1.99

$

Usually ships in 3-6 days

0

27

Honda 34908-KM1-671

BULB, WEDGE BASE (T6.5) (12V 3W)

$11.99

$

Usually ships in 3-6 days

0

28

Honda 37206-ZW5-004

SEE PART DETAILS - SUP; PANEL, INDICATOR (2-BULB)
(Superseded to 37206-ZW5-024)

$38.99

$

Usually ships in 3-6 days

0

29

Honda 37210-ZW5-004

LAMP ASSY., INDICATION (2-BULB)

$

$

Not available

30

Honda 37581-KR3-008

LENS, SPEEDOMETER PILOT

$11.99

$

Usually ships in 3-6 days

0

31

Honda 32901-952-770

TIE, CABLE (NATURAL 2.4X92)

$3.49

$

Usually ships in 3-6 days

0
